8TKM

Murine NF-kappaB p50 Rel Homology Region homodimer in complex with 17-mer kappaB DNA from human interleukin-6 (IL-6) promoter


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.225
  • R-Value Observed: 0.227

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

X-ray Crystallographic Study of Preferred Spacing by the NF-kappa B p50 Homodimer on kappa B DNA.

Zhu, N.Mealka, M.Mitchel, S.Milani, C.Acuna, L.M.Rogers, E.Lahana, A.N.Huxford, T.

(2023) Biomolecules 13

  • DOI: https://doi.org/10.3390/biom13091310
  • Primary Citation of Related Structures:
    8TKL, 8TKM, 8TKN

  • PubMed Abstract:

    Though originally characterized as an inactive or transcriptionally repressive factor, the NF-κB p50 homodimer has become appreciated as a physiologically relevant driver of specific target gene expression. By virtue of its low affinity for cytoplasmic IκB protein inhibitors, p50 accumulates in the nucleus of resting cells, where it is a binding target for the transcriptional co-activator IκBζ. In this study, we employed X-ray crystallography to analyze the structure of the p50 homodimer on κB DNA from the promoters of human interleukin-6 (IL-6) and neutrophil-gelatinase-associated lipocalin (NGAL) genes, both of which respond to IκBζ. The NF-κB p50 homodimer binds 11-bp on IL-6 κB DNA, while, on NGAL κB DNA, the spacing is 12-bp. This begs the question: what DNA binding mode is preferred by NF-κB p50 homodimer? To address this, we engineered a "Test" κB-like DNA containing the core sequence 5'-GGGGAATTCCCC-3' and determined its X-ray crystal structure in complex with p50. This revealed that, when presented with multiple options, NF-κB p50 homodimer prefers to bind 11-bp, which necessarily imposes asymmetry on the complex despite the symmetry inherent in both the protein and its target DNA, and that the p50 dimerization domain can contact DNA via distinct modes.


  • Organizational Affiliation

    Structural Biochemistry Laboratory, Department of Chemistry & Biochemistry, San Diego State University, 5500 Campanile Dr., San Diego, CA 92182-1030, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Nuclear factor NF-kappa-B p50 subunit
A, B
312Mus musculusMutation(s): 0
Gene Names: Nfkb1
UniProt & NIH Common Fund Data Resources
Find proteins for P25799 (Mus musculus)
Explore P25799
Go to UniProtKB:  P25799
IMPC:  MGI:97312
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP25799
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
17-mer kappaB DNA17Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
17-mer kappaB DNA17Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.225
  • R-Value Observed: 0.227
  • Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 162.172α = 90
b = 162.172β = 90
c = 60.384γ = 120
Software Package:
Software NamePurpose
HKL-2000data collection
autoPROCdata processing
PHENIXmodel building
PHENIXrefinement

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2023-10-11
    Type: Initial release
