8T0A | pdb_00008t0a

Crystal structure of integrin beta-2 tail bound to the FERM-folded talin head domain with a Y270E mutation

PDB DOI: https://doi.org/10.2210/pdb8T0A/pdb

Classification: CELL ADHESION
Organism(s): Mus musculus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2023-05-31 Released: 2024-10-30
Deposition Author(s): Wu, J., Gao, T.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.14 Å
R-Value Free:
0.230 (Depositor), 0.229 (DCC)
R-Value Work:
0.183 (Depositor), 0.184 (DCC)
R-Value Observed:
0.186 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8T0A

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of beta-2 in complex with talin in a FERM configuration

Wu, J., Gao, T.

To be published.

Macromolecule Content

Total Structure Weight: 47.37 kDa
Atom Count: 3,326
Modeled Residue Count: 378
Deposited Residue Count: 411
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrin beta-2,Talin-1	A	411	Mus musculus	Mutation(s): 1 Gene Names: Itgb2, Tln1, Tln
UniProt
Find proteins for P11835 (Mus musculus) Explore P11835 Go to UniProtKB: P11835
Find proteins for P26039 (Mus musculus) Explore P26039 Go to UniProtKB: P26039
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	P11835 P26039
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.14 Å
R-Value Free: 0.230 (Depositor), 0.229 (DCC)
R-Value Work: 0.183 (Depositor), 0.184 (DCC)
R-Value Observed: 0.186 (Depositor)

Space Group: P 2₁ 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.775	α = 90
b = 68.644	β = 90
c = 110.386	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-10-30

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM119560

Revision History (Full details and data files)

Version 1.0: 2024-10-30
Type: Initial release
