8SIU

Origin Recognition Complex Associated (ORCA) protein bound to Orc2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.170
  • R-Value Observed: 0.171

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

A dual role for the chromatin reader ORCA/LRWD1 in targeting the origin recognition complex to chromatin.

Sahu, S.Ekundayo, B.E.Kumar, A.Bleichert, F.

(2023) EMBO J 42: e114654-e114654

  • DOI: https://doi.org/10.15252/embj.2023114654
  • Primary Citation of Related Structures:
    8SIU, 8SIY

  • PubMed Abstract:

    Eukaryotic cells use chromatin marks to regulate the initiation of DNA replication. The origin recognition complex (ORC)-associated protein ORCA plays a critical role in heterochromatin replication in mammalian cells by recruiting the initiator ORC, but the underlying mechanisms remain unclear. Here, we report crystal and cryo-electron microscopy structures of ORCA in complex with ORC's Orc2 subunit and nucleosomes, establishing that ORCA orchestrates ternary complex assembly by simultaneously recognizing a highly conserved peptide sequence in Orc2, nucleosomal DNA, and repressive histone trimethylation marks through an aromatic cage. Unexpectedly, binding of ORCA to nucleosomes prevents chromatin array compaction in a manner that relies on H4K20 trimethylation, a histone modification critical for heterochromatin replication. We further show that ORCA is necessary and sufficient to specifically recruit ORC into chromatin condensates marked by H4K20 trimethylation, providing a paradigm for studying replication initiation in specific chromatin contexts. Collectively, our findings support a model in which ORCA not only serves as a platform for ORC recruitment to nucleosomes bearing specific histone marks but also helps establish a local chromatin environment conducive to subsequent MCM2-7 loading.


  • Organizational Affiliation

    Department of Molecular Biophysics and Biochemistry, Yale University, New Haven, CT, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Leucine-rich repeat and WD repeat-containing protein 1383Rattus norvegicusMutation(s): 2
Gene Names: Lrwd1
UniProt
Find proteins for A0A140UHX1 (Rattus norvegicus)
Explore A0A140UHX1
Go to UniProtKB:  A0A140UHX1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A140UHX1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Origin recognition complex subunit 2103Rattus norvegicusMutation(s): 0
Gene Names: Orc2Orc2l
UniProt
Find proteins for Q75PQ8 (Rattus norvegicus)
Explore Q75PQ8
Go to UniProtKB:  Q75PQ8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ75PQ8
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.203
  • R-Value Work: 0.170
  • R-Value Observed: 0.171
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.023α = 90
b = 135.431β = 90
c = 78.567γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States5R01GM141313
European Research Council (ERC)European UnionERC-STG-757909

Revision History  (Full details and data files)

  • Version 1.0: 2023-08-02
    Type: Initial release
  • Version 1.1: 2023-08-30
    Changes: Data collection, Database references
  • Version 1.2: 2023-09-27
    Changes: Database references
  • Version 1.3: 2023-11-15
    Changes: Data collection
