8K1S | pdb_00008k1s

Potassium transporter KtrAB from Bacillus subtilis in ADP-bound state


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.83 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8K1S

This is version 1.2 of the entry. See complete history

Literature

Structural basis and synergism of ATP and Na + activation in bacterial K + uptake system KtrAB.

Chiang, W.T.Chang, Y.K.Hui, W.H.Chang, S.W.Liao, C.Y.Chang, Y.C.Chen, C.J.Wang, W.C.Lai, C.C.Wang, C.H.Luo, S.Y.Huang, Y.P.Chou, S.H.Horng, T.L.Hou, M.H.Muench, S.P.Chen, R.S.Tsai, M.D.Hu, N.J.

(2024) Nat Commun 15: 3850-3850

  • DOI: https://doi.org/10.1038/s41467-024-48057-y
  • Primary Citation Related Structures:
    8K16, 8K1K, 8K1S, 8K1T, 8K1U, 8XMH, 8XMI

  • PubMed Abstract:

    The K + uptake system KtrAB is essential for bacterial survival in low K + environments. The activity of KtrAB is regulated by nucleotides and Na + . Previous studies proposed a putative gating mechanism of KtrB regulated by KtrA upon binding to ATP or ADP. However, how Na + activates KtrAB and the Na + binding site remain unknown. Here we present the cryo-EM structures of ATP- and ADP-bound KtrAB from Bacillus subtilis (BsKtrAB) both solved at 2.8 Å. A cryo-EM density at the intra-dimer interface of ATP-KtrA was identified as Na + , as supported by X-ray crystallography and ICP-MS. Thermostability assays and functional studies demonstrated that Na + binding stabilizes the ATP-bound BsKtrAB complex and enhances its K + flux activity. Comparing ATP- and ADP-BsKtrAB structures suggests that BsKtrB Arg417 and Phe91 serve as a channel gate. The synergism of ATP and Na + in activating BsKtrAB is likely applicable to Na + -activated K + channels in central nervous system.


  • Organizational Affiliation
    • Graduate Institute of Biochemistry, National Chung Hsing University, Taichung, 402202, Taiwan.

Macromolecule Content

  • Total Structure Weight: 396.79 kDa
  • Atom Count: 21,000
  • Modeled Residue Count: 2,695
  • Deposited Residue Count: 3,556
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Ktr system potassium uptake protein A
A, B, C, D, E
A, B, C, D, E, F, G, H
222Bacillus subtilisMutation(s): 0
Gene Names: ktrAyuaABSU31090
Membrane Entity: Yes
UniProt
Find proteins for O32080 (Bacillus subtilis (strain 168))
Explore O32080
Go to UniProtKB:  O32080
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO32080
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Ktr system potassium uptake protein B
I, J, K, L
445Bacillus subtilisMutation(s): 0
Gene Names: ktrByubGBSU31100
Membrane Entity: Yes
UniProt
Find proteins for O32081 (Bacillus subtilis (strain 168))
Explore O32081
Go to UniProtKB:  O32081
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO32081
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP
(Subject of Investigation/LOI)

Query on ADP



Download:Ideal Coordinates CCD File
M [auth A]
N [auth B]
O [auth C]
P [auth D]
Q [auth E]
M [auth A],
N [auth B],
O [auth C],
P [auth D],
Q [auth E],
R [auth F],
S [auth G],
T [auth H]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
K
(Subject of Investigation/LOI)

Query on K



Download:Ideal Coordinates CCD File
U [auth I],
V [auth J],
W [auth K],
X [auth L]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.83 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.19.2
RECONSTRUCTIONcryoSPARC3.2

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Academia Sinica (Taiwan)Taiwan--

Revision History  (Full details and data files)

  • Version 1.0: 2024-04-03
    Type: Initial release
  • Version 1.1: 2024-05-15
    Changes: Database references
  • Version 1.2: 2024-05-22
    Changes: Database references
