8GRW

Spiroplasma melliferum FtsZ F224M bound to GDP

• PDB DOI: https://doi.org/10.2210/pdb8GRW/pdb

• Classification: CELL CYCLE
• Organism(s): Spiroplasma melliferum KC3
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2022-09-02 Released: 2023-09-06
• Deposition Author(s): Chakraborty, J., Pananghat, G.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free: 0.238
• R-Value Work: 0.193
• R-Value Observed: 0.196

Literature

Structural basis of kinetic polarity of FtsZ from cell wall less bacterium Spiroplasma

Chakraborty, J., Pananghat, G.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 68.24 kDa
• Atom Count: 4,334
• Modelled Residue Count: 589
• Deposited Residue Count: 644
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cell division protein FtsZ	A, B	322	Spiroplasma melliferum KC3	Mutation(s): 1  Gene Names: ftsZ, SPM_000165
UniProt
Find proteins for A0A4D8RL11 (Spiroplasma melliferum) Explore A0A4D8RL11  Go to UniProtKB:  A0A4D8RL11

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GDP (Subject of Investigation/LOI)	D [auth A], E [auth B]	GUANOSINE-5'-DIPHOSPHATE C10 H15 N5 O11 P2 QGWNDRXFNXRZMB-UUOKFMHZSA-N
TRS	C [auth A]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C4 H12 N O3 LENZDBCJOHFCAS-UHFFFAOYSA-O

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free: 0.238
• R-Value Work: 0.193
• R-Value Observed: 0.196
• Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 106.669	α = 90
b = 106.669	β = 90
c = 128.781	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-09-06
Deposition Author(s): Chakraborty, J., Pananghat, G.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-09-06
  Type: Initial release
