8EZR

Crystal structure of the HipS(Lp)-HipT(Lp) complex from Legionella pneumophila, native protein

• PDB DOI: https://doi.org/10.2210/pdb8EZR/pdb

• Classification: TOXIN
• Organism(s): Legionella pneumophila
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2022-11-01 Released: 2023-09-27
• Deposition Author(s): Stogios, P.J., Skarina, T., Michalska, K., Di Leo, R., Lin, J., Ensminger, A., Savchenko, A., Joachimiak, A., Satchell, K.J.F., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free: 0.261
• R-Value Work: 0.213
• R-Value Observed: 0.215

Literature

Crystal structure of the HipS(Lp)-HipT(Lp) complex from Legionella pneumophila, native protein

Stogios, P.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 47.84 kDa
• Atom Count: 3,222
• Modelled Residue Count: 373
• Deposited Residue Count: 414
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HipS(Lp)	A	102	Legionella pneumophila	Mutation(s): 0  Gene Names: lpg2369
UniProt
Find proteins for Q5ZSZ7 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZSZ7  Go to UniProtKB:  Q5ZSZ7

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
HipT(Lp)	B	312	Legionella pneumophila	Mutation(s): 0  Gene Names: lpg2370
UniProt
Find proteins for Q5ZSZ6 (Legionella pneumophila subsp. pneumophila (strain Philadelphia 1 / ATCC 33152 / DSM 7513)) Explore Q5ZSZ6  Go to UniProtKB:  Q5ZSZ6

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	C [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
CL	D [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.95 Å
• R-Value Free: 0.261
• R-Value Work: 0.213
• R-Value Observed: 0.215
• Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.038	α = 90
b = 45.038	β = 90
c = 393.97	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
PHENIX	phasing
PHENIX	model building
Coot	model building

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-09-27
Deposition Author(s): Stogios, P.J., Skarina, T., Michalska, K., Di Leo, R., Lin, J., Ensminger, A., Savchenko, A., Joachimiak, A., Satchell, K.J.F., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History

• Version 1.0: 2023-09-27
  Type: Initial release
