8EKI

CryoEM structure of the Dsl1 complex bound to SNAREs Sec20 and Use1


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Structure of a membrane tethering complex incorporating multiple SNAREs.

DAmico, K.A.Stanton, A.E.Shirkey, J.D.Travis, S.M.Jeffrey, P.D.Hughson, F.M.

(2024) Nat Struct Mol Biol 31: 246-254

  • DOI: https://doi.org/10.1038/s41594-023-01164-8
  • Primary Citation of Related Structures:
    8EKI, 8FTU

  • PubMed Abstract:

    Most membrane fusion reactions in eukaryotic cells are mediated by multisubunit tethering complexes (MTCs) and SNARE proteins. MTCs are much larger than SNAREs and are thought to mediate the initial attachment of two membranes. Complementary SNAREs then form membrane-bridging complexes whose assembly draws the membranes together for fusion. Here we present a cryo-electron microscopy structure of the simplest known MTC, the 255-kDa Dsl1 complex of Saccharomyces cerevisiae, bound to the two SNAREs that anchor it to the endoplasmic reticulum. N-terminal domains of the SNAREs form an integral part of the structure, stabilizing a Dsl1 complex configuration with unexpected similarities to the 850-kDa exocyst MTC. The structure of the SNARE-anchored Dsl1 complex and its comparison with exocyst reveal what are likely to be common principles underlying MTC function. Our structure also implies that tethers and SNAREs can work together as a single integrated machine.


  • Organizational Affiliation

    Department of Molecular Biology, Princeton University, Princeton, NJ, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protein transport protein SEC20275Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: SEC20YDR498CD9719.4
UniProt
Find proteins for P28791 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P28791
Go to UniProtKB:  P28791
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28791
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Protein transport protein USE1212Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: USE1SLT1YGL098W
UniProt
Find proteins for P53146 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53146
Go to UniProtKB:  P53146
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53146
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Protein transport protein TIP20701Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: TIP20TIP1YGL145W
UniProt
Find proteins for P33891 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P33891
Go to UniProtKB:  P33891
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP33891
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Protein transport protein SEC39709Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: SEC39DSL3YLR440C
UniProt
Find proteins for Q12745 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12745
Go to UniProtKB:  Q12745
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12745
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Protein transport protein DSL1783Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: DSL1YNL258CN0842
UniProt
Find proteins for P53847 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53847
Go to UniProtKB:  P53847
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53847
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 4.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
RECONSTRUCTIONCoot0.8.9.1

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM071574
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesT32GM007388

Revision History  (Full details and data files)

  • Version 1.0: 2023-10-04
    Type: Initial release
  • Version 1.1: 2024-01-17
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Database references
  • Version 1.3: 2024-02-28
    Changes: Database references
