8B3K

Crystal structure of human Plexin-B1 (20-535) in the unbound state

PDB DOI: https://doi.org/10.2210/pdb8B3K/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2022-09-16 Released: 2023-05-03
Deposition Author(s): Cowan, R., Hall, G., Carr, M.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.69 Å
R-Value Free: 0.245
R-Value Work: 0.199

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Nanobody inhibitors of Plexin-B1 identify allostery in plexin-semaphorin interactions and signaling.

Cowan, R., Trokter, M., Oleksy, A., Fedorova, M., Sawmynaden, K., Worzfeld, T., Offermanns, S., Matthews, D., Carr, M.D., Hall, G.

(2023) J Biol Chem 299: 104740-104740

PubMed: 37088134 Search on PubMedSearch on PubMed Central
DOI: https://doi.org/10.1016/j.jbc.2023.104740
Primary Citation of Related Structures:
8B3K, 8BB7, 8BF4

PubMed Abstract:
Plexin-B1 is a receptor for the cell surface semaphorin, Sema4D. This signaling system has been implicated in a variety of human diseases, including cancer, multiple sclerosis and osteoporosis. While inhibitors of the Plexin-B1:Sema4D interaction have been previously reported, understanding their mechanism has been hindered by an incomplete structural view of Plexin-B1. In this study, we have raised and characterized a pair of nanobodies that are specific for mouse Plexin-B1 and which inhibit the binding of Sema4D to mouse Plexin-B1 and its biological activity. Structural studies of these nanobodies reveal that they inhibit the binding of Sema4D in an allosteric manner, binding to epitopes not previously reported. In addition, we report the first unbound structure of human Plexin-B1, which reveals that Plexin-B1 undergoes a conformational change on Sema4D binding. These changes mirror those seen upon binding of allosteric peptide modulators, which suggests a new model for understanding Plexin-B1 signaling and provides a potential innovative route for therapeutic modulation of Plexin-B1.

Organizational Affiliation

Department of Molecular and Cell Biology, Leicester Institute of Structural and Chemical Biology, University of Leicester, Leicester, UK.

Macromolecule Content

Total Structure Weight: 114.97 kDa
Atom Count: 7,722
Modelled Residue Count: 984
Deposited Residue Count: 1,046
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Plexin-B1	A [auth B], B [auth A]	523	Homo sapiens	Mutation(s): 0 Gene Names: PLXNB1, KIAA0407, PLXN5, SEP
UniProt & NIH Common Fund Data Resources
Find proteins for O43157 (Homo sapiens) Explore O43157 Go to UniProtKB: O43157
PHAROS: O43157 GTEx: ENSG00000164050
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O43157
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain R [auth A] MOL2 format, chain J [auth B] MOL2 format, chain R [auth A]	J [auth B], R [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain J [auth B] Focus chain R [auth A] Interactions & Density Focus chain J [auth B] Focus chain R [auth A]
CD Query on CD Download Ideal Coordinates CCD File SDF format, chain C [auth B] SDF format, chain D [auth B] SDF format, chain E [auth B] SDF format, chain F [auth B] SDF format, chain G [auth B] SDF format, chain H [auth B] SDF format, chain I [auth B] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] MOL2 format, chain C [auth B] MOL2 format, chain D [auth B] MOL2 format, chain E [auth B] MOL2 format, chain F [auth B] MOL2 format, chain G [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A]	C [auth B] D [auth B] E [auth B] F [auth B] G [auth B] C [auth B], D [auth B], E [auth B], F [auth B], G [auth B], H [auth B], I [auth B], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A], Q [auth A]	CADMIUM ION Cd WLZRMCYVCSSEQC-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Focus chain D [auth B] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Interactions & Density Focus chain C [auth B] Focus chain D [auth B] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A]
