TRIM7 PRYSPRY in complex with a 2BC peptide TIEALFQ

Experimental Data Snapshot

  • Resolution: 1.62 Å
  • R-Value Free: 0.188
  • R-Value Work: 0.156

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


TRIM7 Restricts Coxsackievirus and Norovirus Infection by Detecting the C-Terminal Glutamine Generated by 3C Protease Processing.

Luptak, J.Mallery, D.L.Jahun, A.S.Albecka, A.Clift, D.Ather, O.Slodkowicz, G.Goodfellow, I.James, L.C.

(2022) Viruses 14

  • DOI: https://doi.org/10.3390/v14081610
  • Primary Citation of Related Structures:
    8A5L, 8A5M, 8A8X

  • PubMed Abstract:

    TRIM7 catalyzes the ubiquitination of multiple substrates with unrelated biological functions. This cross-reactivity is at odds with the specificity usually displayed by enzymes, including ubiquitin ligases. Here we show that TRIM7's extreme substrate promiscuity is due to a highly unusual binding mechanism, in which the PRYSPRY domain captures any ligand with a C-terminal helix that terminates in a hydrophobic residue followed by a glutamine. Many of the non-structural proteins found in RNA viruses contain C-terminal glutamines as a result of polyprotein cleavage by 3C protease. This viral processing strategy generates novel substrates for TRIM7 and explains its ability to inhibit Coxsackie virus and norovirus replication. In addition to viral proteins, cellular proteins such as glycogenin have evolved C-termini that make them a TRIM7 substrate. The 'helix-ΦQ' degron motif recognized by TRIM7 is reminiscent of the N-end degron system and is found in ~1% of cellular proteins. These features, together with TRIM7's restricted tissue expression and lack of immune regulation, suggest that viral restriction may not be its physiological function.

  • Organizational Affiliation

    MRC Laboratory of Molecular Biology, Francis Crick Avenue, Cambridge CB2 0QH, UK.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase TRIM7179Homo sapiensMutation(s): 0
Gene Names: TRIM7GNIPRNF90
UniProt & NIH Common Fund Data Resources
Find proteins for Q9C029 (Homo sapiens)
Explore Q9C029
Go to UniProtKB:  Q9C029
GTEx:  ENSG00000146054
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9C029
Sequence Annotations
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
2BC peptide TIEALFQ7Enterovirus A71Mutation(s): 0
Find proteins for B9VUU3 (Human enterovirus 71)
Explore B9VUU3
Go to UniProtKB:  B9VUU3
Entity Groups
UniProt GroupB9VUU3
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on TAR

Download Ideal Coordinates CCD File
C4 H6 O6
Experimental Data & Validation

Experimental Data

  • Resolution: 1.62 Å
  • R-Value Free: 0.188
  • R-Value Work: 0.156
  • Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.887α = 90
b = 79.887β = 90
c = 53.205γ = 120
Software Package:
Software NamePurpose
xia2data reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

  • Released Date: 2022-07-06
  • Deposition Author(s): Luptak, J.

Funding OrganizationLocationGrant Number
Medical Research Council (MRC, United Kingdom)United Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2022-07-06
    Type: Initial release
  • Version 1.1: 2022-08-03
    Changes: Database references
  • Version 1.2: 2022-08-10
    Changes: Database references
  • Version 1.3: 2024-01-31
    Changes: Data collection, Refinement description
