8A3X

Imine Reductase from Ensifer adhaerens in complex with NADP+


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.58 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.236
  • R-Value Observed: 0.238

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

A Reductive Aminase Switches to Imine Reductase Mode for a Bulky Amine Substrate.

Gilio, A.K.Thorpe, T.W.Heyam, A.Petchey, M.R.Pogranyi, B.France, S.P.Howard, R.M.Karmilowicz, M.J.Lewis, R.Turner, N.Grogan, G.

(2023) ACS Catal 13: 1669-1677

  • DOI: https://doi.org/10.1021/acscatal.2c06066
  • Primary Citation of Related Structures:
    8A3X, 8A5Z

  • PubMed Abstract:

    Imine reductases (IREDs) catalyze the asymmetric reduction of cyclic imines, but also in some cases the coupling of ketones and amines to form secondary amine products in an enzyme-catalyzed reductive amination (RedAm) reaction. Enzymatic RedAm reactions have typically used small hydrophobic amines, but many interesting pharmaceutical targets require that larger amines be used in these coupling reactions. Following the identification of IR77 from Ensifer adhaerens as a promising biocatalyst for the reductive amination of cyclohexanone with pyrrolidine, we have characterized the ability of this enzyme to catalyze couplings with larger bicyclic amines such as isoindoline and octahydrocyclopenta( c )pyrrole. By comparing the activity of IR77 with reductions using sodium cyanoborohydride in water, it was shown that, while the coupling of cyclohexanone and pyrrolidine involved at least some element of reductive amination, the amination with the larger amines likely occurred ex situ, with the imine recruited from solution for enzyme reduction. The structure of IR77 was determined, and using this as a basis, structure-guided mutagenesis, coupled with point mutations selecting improving amino acid sites suggested by other groups, permitted the identification of a mutant A208N with improved activity for amine product formation. Improvements in conversion were attributed to greater enzyme stability as revealed by X-ray crystallography and nano differential scanning fluorimetry. The mutant IR77-A208N was applied to the preparative scale amination of cyclohexanone at 50 mM concentration, with 1.2 equiv of three larger amines, in isolated yields of up to 93%.


  • Organizational Affiliation

    Department of Chemistry, University of York, Heslington, York YO10 5DD, U.K.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NAD_binding_2 domain-containing protein
A, B, C, D
296Ensifer adhaerensMutation(s): 0
Gene Names: AC244_29830
UniProt
Find proteins for A0A0L8BGL4 (Ensifer adhaerens)
Explore A0A0L8BGL4
Go to UniProtKB:  A0A0L8BGL4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0L8BGL4
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.58 Å
  • R-Value Free: 0.281
  • R-Value Work: 0.236
  • R-Value Observed: 0.238
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 90.959α = 90
b = 57.535β = 94.96
c = 116.441γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
SCALAdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2023-03-08
    Type: Initial release
  • Version 1.1: 2023-03-15
    Changes: Database references
  • Version 1.2: 2024-02-07
    Changes: Data collection, Refinement description
