7WWJ | pdb_00007wwj

SARS-CoV-2 BA.1 Spike trimer in complex with 55A8 Fab in the class 2 conformation

PDB DOI: https://doi.org/10.2210/pdb7WWJ/pdb
EM Map EMD-32867: EMDB EMDataResource

Classification: VIRAL PROTEIN/IMMUNE SYSTEM
Organism(s): Severe acute respiratory syndrome coronavirus 2, Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2022-02-13 Released: 2023-02-15
Deposition Author(s): Guo, H., Gao, Y., Lu, Y., Yang, H., Ji, X.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.50 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7WWJ

This is version 1.3 of the entry. See complete history.

Literature

EM structure of SARS-CoV-2 Omicron variant spike glycoprotein and 55A8

Guo, H., Gao, Y., Lu, Y., Yang, H., Ji, X.

To be published.

Macromolecule Content

Total Structure Weight: 461.07 kDa
Atom Count: 26,915
Modeled Residue Count: 3,367
Deposited Residue Count: 4,073
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,205	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 39 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTC2
Glycosylation
Glycosylation Sites: 9	Glycosylation Focus chain A Focus chain B Focus chain C	Go to GlyGen: P0DTC2-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
55A8 light chain	D [auth F], F [auth H]	108	Homo sapiens	Mutation(s): 0

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
55A8 heavy chain	E [auth G], G [auth I]	121	Homo sapiens	Mutation(s): 0

Oligosaccharides

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	H [auth O], I [auth D], J [auth E], K [auth J], L [auth K], H [auth O], I [auth D], J [auth E], K [auth J], L [auth K], M [auth L], N [auth M], O [auth N], P, Q, R, S, T, U	2		N-Glycosylation	Interactions Focus chain H [auth O] Focus chain I [auth D] Focus chain J [auth E] Focus chain K [auth J] Focus chain L [auth K] Focus chain M [auth L] Focus chain N [auth M] Focus chain O [auth N] Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Interactions & Density Focus chain H [auth O] Focus chain I [auth D] Focus chain J [auth E] Focus chain K [auth J] Focus chain L [auth K] Focus chain M [auth L] Focus chain N [auth M] Focus chain O [auth N] Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain FA [auth C] SDF format, chain GA [auth C] SDF format, chain HA [auth C] SDF format, chain IA [auth C] SDF format, chain JA [auth C] SDF format, chain V [auth A] SDF format, chain W [auth A] SDF format, chain X [auth A] SDF format, chain Z [auth A] SDF format, chain Y [auth A] SDF format, chain EA [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain FA [auth C] MOL2 format, chain GA [auth C] MOL2 format, chain HA [auth C] MOL2 format, chain IA [auth C] MOL2 format, chain JA [auth C] MOL2 format, chain V [auth A] MOL2 format, chain W [auth A] MOL2 format, chain X [auth A] MOL2 format, chain Z [auth A] MOL2 format, chain Y [auth A] MOL2 format, chain EA [auth B] mmCIF format, chain AA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain CA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain FA [auth C] mmCIF format, chain GA [auth C] mmCIF format, chain HA [auth C] mmCIF format, chain IA [auth C] mmCIF format, chain JA [auth C] mmCIF format, chain V [auth A] mmCIF format, chain W [auth A] mmCIF format, chain X [auth A] mmCIF format, chain Z [auth A] mmCIF format, chain Y [auth A] mmCIF format, chain EA [auth B]	AA [auth B] BA [auth B] CA [auth B] DA [auth B] EA [auth B] AA [auth B], BA [auth B], CA [auth B], DA [auth B], EA [auth B], FA [auth C], GA [auth C], HA [auth C], IA [auth C], JA [auth C], V [auth A], W [auth A], X [auth A], Y [auth A], Z [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth C] Focus chain GA [auth C] Focus chain HA [auth C] Focus chain IA [auth C] Focus chain JA [auth C] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth C] Focus chain GA [auth C] Focus chain HA [auth C] Focus chain IA [auth C] Focus chain JA [auth C] Focus chain V [auth A] Focus chain W [auth A] Focus chain X [auth A] Focus chain Y [auth A] Focus chain Z [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.50 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-02-15

Deposition Author(s):

Funding Organization	Location	Grant Number
Other government	China	--

Revision History (Full details and data files)

Version 1.0: 2023-02-15
Type: Initial release
Version 1.1: 2023-04-19
Changes: Structure summary
Version 1.2: 2024-11-06
Changes: Data collection, Structure summary
Version 1.3: 2025-07-02
Changes: Data collection
