Yeast Lon (PIM1) with endogenous substrate

Experimental Data Snapshot

  • Resolution: 3.30 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Cryo-EM structure of hexameric yeast Lon protease (PIM1) highlights the importance of conserved structural elements.

Yang, J.Song, A.S.Wiseman, R.L.Lander, G.C.

(2022) J Biol Chem 298: 101694-101694

  • DOI: https://doi.org/10.1016/j.jbc.2022.101694
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Lon protease is a conserved ATP-dependent serine protease composed of an AAA+ domain that mechanically unfolds substrates and a serine protease domain that degrades these unfolded substrates. In yeast, dysregulation of Lon protease (PIM1) attenuates lifespan and leads to gross mitochondrial morphological perturbations. Although structures of the bacterial and human Lon protease reveal a hexameric assembly, yeast PIM1 was speculated to form a heptameric assembly and is uniquely characterized by a ∼50-residue insertion between the ATPase and protease domains. To further understand the yeast-specific properties of PIM1, we determined a high-resolution cryo-electron microscopy structure of PIM1 in a substrate-translocating state. Here, we reveal that PIM1 forms a hexamer, conserved with that of bacterial and human Lon proteases, wherein the ATPase domains form a canonical closed spiral that enables pore loop residues to translocate substrates to the protease chamber. In the substrate-translocating state, PIM1 protease domains form a planar protease chamber in an active conformation and are uniquely characterized by a ∼15-residue C-terminal extension. These additional C-terminal residues form an α-helix located along the base of the protease domain. Finally, we did not observe density for the yeast-specific insertion between the ATPase and protease domains, likely due to high conformational flexibility. Biochemical studies to investigate the insertion using constructs that truncated or replaced the insertion with a glycine-serine linker suggest that the yeast-specific insertion is dispensable for PIM1's enzymatic function. Altogether, our structural and biochemical studies highlight unique components of PIM1 machinery and demonstrate evolutionary conservation of Lon protease function.

  • Organizational Affiliation

    Department of Integrative, Structural and Computational Biology, Scripps Research, La Jolla, California, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Lon protease homolog, mitochondrial
A, B, C, D, E
A, B, C, D, E, F
968Saccharomyces cerevisiae S288CMutation(s): 0
Gene Names: PIM1LONYBL022CYBL0440
Find proteins for P36775 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P36775
Go to UniProtKB:  P36775
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP36775
Sequence Annotations
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
endogenous substrate12Escherichia coliMutation(s): 0
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP (Subject of Investigation/LOI)
Query on ATP

Download Ideal Coordinates CCD File
H [auth A],
L [auth D],
N [auth E],
Q [auth F]
C10 H16 N5 O13 P3
ADP (Subject of Investigation/LOI)
Query on ADP

Download Ideal Coordinates CCD File
J [auth B],
K [auth C]
C10 H15 N5 O10 P2
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
I [auth A],
M [auth D],
O [auth E],
P [auth E]
Experimental Data & Validation

Experimental Data

  • Resolution: 3.30 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Neurological Disorders and Stroke (NIH/NINDS)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2022-01-12
    Type: Initial release
  • Version 1.1: 2022-07-27
    Changes: Database references
