7SBL

One RBD-up 1 of pre-fusion SARS-CoV-2 Delta variant spike protein


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

Membrane fusion and immune evasion by the spike protein of SARS-CoV-2 Delta variant.

Zhang, J.Xiao, T.Cai, Y.Lavine, C.L.Peng, H.Zhu, H.Anand, K.Tong, P.Gautam, A.Mayer, M.L.Walsh Jr., R.M.Rits-Volloch, S.Wesemann, D.R.Yang, W.Seaman, M.S.Lu, J.Chen, B.

(2021) Science 374: 1353-1360


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Spike glycoproteinA, B, C1308Severe acute respiratory syndrome coronavirus 2Mutation(s): 8
Gene Names: S2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTC2
Go to UniProtKB:  P0DTC2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTC2
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
CA [auth c],
D,
DA [auth d],
EA [auth e],
J,
CA [auth c],
D,
DA [auth d],
EA [auth e],
J,
K,
L,
R,
S,
T
3N/AN-Glycosylation Oligosaccharides Interaction
Entity ID: 3
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
AA [auth a],
E,
F,
FA [auth f],
G,
AA [auth a],
E,
F,
FA [auth f],
G,
H,
M,
N,
O,
P,
U,
V,
W,
X,
Y,
Z
2N/AN-Glycosylation Oligosaccharides Interaction
Entity ID: 4
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranoseBA [auth b],
I,
Q
3N/AN-Glycosylation Oligosaccharides Interaction
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
NAG (Subject of Investigation/LOI)
Query on NAG

Download Ideal Coordinates CCD File
AB [auth C],
BB [auth C],
CB [auth C],
DB [auth C],
EB [auth C],
AB [auth C],
BB [auth C],
CB [auth C],
DB [auth C],
EB [auth C],
GA [auth A],
HA [auth A],
IA [auth A],
JA [auth A],
KA [auth A],
LA [auth A],
MA [auth A],
NA [auth A],
OA [auth A],
PA [auth B],
QA [auth B],
RA [auth B],
SA [auth B],
TA [auth B],
UA [auth B],
VA [auth B],
WA [auth B],
XA [auth B],
YA [auth C],
ZA [auth C]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report




Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI147884
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI141002
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI127193
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI39538

Revision History  (Full details and data files)

  • Version 1.0: 2021-11-10
    Type: Initial release
  • Version 2.0: 2021-11-17
    Type: Coordinate replacement
    Reason: Ligand identity
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
  • Version 2.1: 2021-12-22
    Changes: Database references
