7WSB

The ternary complex structure of FtmOx1 with a-ketoglutarate and 13-oxo-fumitremorgin B


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.87 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.161
  • R-Value Observed: 0.162

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Dissecting the Mechanism of the Nonheme Iron Endoperoxidase FtmOx1 Using Substrate Analogues.

Zhu, G.Yan, W.Wang, X.Cheng, R.Naowarojna, N.Wang, K.Wang, J.Song, H.Wang, Y.Liu, H.Xia, X.Costello, C.E.Liu, X.Zhang, L.Liu, P.

(2022) JACS Au 2: 1686-1698

  • DOI: https://doi.org/10.1021/jacsau.2c00248
  • Primary Citation of Related Structures:
    7WSB

  • PubMed Abstract:

    FtmOx1 is a nonheme iron (NHFe) endoperoxidase, catalyzing three disparate reactions, endoperoxidation, alcohol dehydrogenation, and dealkylation, under in vitro conditions; the diversity complicates its mechanistic studies. In this study, we use two substrate analogues to simplify the FtmOx1-catalyzed reaction to either a dealkylation or an alcohol dehydrogenation reaction for structure-function relationship analysis to address two key FtmOx1 mechanistic questions: (1) Y224 flipping in the proposed COX-like model vs α-ketoglutarate (αKG) rotation proposed in the CarC-like mechanistic model and (2) the involvement of a Y224 radical (COX-like model) or a Y68 radical (CarC-like model) in FtmOx1-catalysis. When 13-oxo-fumitremorgin B ( 7 ) is used as the substrate, FtmOx1-catalysis changes from the endoperoxidation to a hydroxylation reaction and leads to dealkylation. In addition, consistent with the dealkylation side-reaction in the COX-like model prediction, the X-ray structure of the FtmOx1•Co II •αKG• 7 ternary complex reveals a flip of Y224 to an alternative conformation relative to the FtmOx1•Fe II •αKG binary complex. Verruculogen ( 2 ) was used as a second substrate analogue to study the alcohol dehydrogenation reaction to examine the involvement of the Y224 radical or Y68 radical in FtmOx1-catalysis, and again, the results from the verruculogen reaction are more consistent with the COX-like model.


  • Organizational Affiliation

    State Key Laboratory of Bioreactor Engineering, East China University of Science and Technology, Shanghai 200237, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Verruculogen synthase
A, B, C, D, E
A, B, C, D, E, F
319Aspergillus fumigatus Af293Mutation(s): 0
Gene Names: ftmOx1ftmFAFUA_8G00230
EC: 1.14.11.38
UniProt
Find proteins for Q4WAW9 (Aspergillus fumigatus (strain ATCC MYA-4609 / CBS 101355 / FGSC A1100 / Af293))
Explore Q4WAW9
Go to UniProtKB:  Q4WAW9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ4WAW9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
4IL (Subject of Investigation/LOI)
Query on 4IL

Download Ideal Coordinates CCD File
AA [auth F]
H [auth A]
M [auth B]
Q [auth C]
T [auth D]
AA [auth F],
H [auth A],
M [auth B],
Q [auth C],
T [auth D],
X [auth E]
13-Oxofumitremorgin B
C27 H31 N3 O5
PKXCLEPXRNTYPU-BKCZMFJTSA-N
AKG
Query on AKG

Download Ideal Coordinates CCD File
BA [auth F]
I [auth A]
N [auth B]
R [auth C]
U [auth D]
BA [auth F],
I [auth A],
N [auth B],
R [auth C],
U [auth D],
Y [auth E]
2-OXOGLUTARIC ACID
C5 H6 O5
KPGXRSRHYNQIFN-UHFFFAOYSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
J [auth A],
O [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
K [auth A],
V [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CO
Query on CO

Download Ideal Coordinates CCD File
G [auth A]
L [auth B]
P [auth C]
S [auth D]
W [auth E]
G [auth A],
L [auth B],
P [auth C],
S [auth D],
W [auth E],
Z [auth F]
COBALT (II) ION
Co
XLJKHNWPARRRJB-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.87 Å
  • R-Value Free: 0.211
  • R-Value Work: 0.161
  • R-Value Observed: 0.162
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 104.05α = 90
b = 85.447β = 108.838
c = 160.768γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2022-07-06
    Type: Initial release
  • Version 1.1: 2022-08-17
    Changes: Database references
  • Version 1.2: 2023-11-29
    Changes: Data collection, Refinement description
