7WJZ | pdb_00007wjz

Omicron Spike bitrimer with 6m6 antibody

• PDB DOI: https://doi.org/10.2210/pdb7WJZ/pdb
• EM Map EMD-32553: EMDB EMDataResource

• Classification: VIRAL PROTEIN
• Organism(s): Severe acute respiratory syndrome coronavirus 2, Homo sapiens
• Expression System: Homo sapiens
• Mutation(s): Yes


• Deposited: 2022-01-08 Released: 2022-07-13
• Deposition Author(s): Zhan, W.Q., Zhang, X., Chen, Z.G., Sun, L.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.34 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

A broadly neutralizing antibody against SARS-CoV-2 Omicron variant infection exhibiting a novel trimer dimer conformation in spike protein binding.

Wang, Y., Zhan, W., Liu, J., Wang, Y., Zhang, X., Zhang, M., Han, L., Ma, Y., Lu, L., Wen, Y., Chen, Z., Zhao, J., Wu, F., Sun, L., Huang, J.

(2022) Cell Res 32: 862-865

• PubMed: 35768499
• DOI: https://doi.org/10.1038/s41422-022-00684-0
• Primary Citation Related Structures:
  7WJY, 7WJZ, 7WK0

---

Organizational Affiliation:
• Key Laboratory of Medical Molecular Virology (MOE/NHC/CAMS) and Shanghai Institute of Infectious Disease and Biosecurity, Shanghai Fifth People's Hospital, Shanghai Public Health Clinical Center, Institutes of Biomedical Sciences, School of Basic Medical Sciences, Fudan University, Shanghai, China.
Shanghai Immune Therapy Institute, Shanghai Jiao Tong University School of Medicine Affiliated Renji Hospital, Shanghai, China.
State Key Laboratory of Respiratory Disease, National Clinical Research Center for Respiratory Disease, Guangzhou Institute of Respiratory Health, the First Affiliated Hospital of Guangzhou Medical University, Guangzhou, Guangdong, China.
State Key Laboratory of Respiratory Disease, National Clinical Research Center for Respiratory Disease, Guangzhou Institute of Respiratory Health, the First Affiliated Hospital of Guangzhou Medical University, Guangzhou, Guangdong, China. [e-mail].
Institute of Infectious Disease, Guangzhou Eighth People's Hospital of Guangzhou Medical University, Guangzhou, Guangdong, China. [e-mail].
Shanghai Immune Therapy Institute, Shanghai Jiao Tong University School of Medicine Affiliated Renji Hospital, Shanghai, China. [e-mail].
Key Laboratory of Medical Molecular Virology (MOE/NHC/CAMS) and Shanghai Institute of Infectious Disease and Biosecurity, Shanghai Fifth People's Hospital, Shanghai Public Health Clinical Center, Institutes of Biomedical Sciences, School of Basic Medical Sciences, Fudan University, Shanghai, China. [e-mail].
Key Laboratory of Medical Molecular Virology (MOE/NHC/CAMS) and Shanghai Institute of Infectious Disease and Biosecurity, Shanghai Fifth People's Hospital, Shanghai Public Health Clinical Center, Institutes of Biomedical Sciences, School of Basic Medical Sciences, Fudan University, Shanghai, China. [e-mail].

Biological Assembly 1

Global Symmetry: Dihedral - D3  (Explore in 3D)
Global Stoichiometry: Hetero 18-mer - A6B6C6

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 1,148.16 kDa
• Atom Count: 69,158
• Modeled Residue Count: 8,886
• Deposited Residue Count: 10,356
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A [auth B], D [auth I], G [auth J], J [auth K], M [auth L], P [auth M]	1,285	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 39  Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2  Go to UniProtKB:  P0DTC2
Glycosylation
Glycosylation Sites: 10		Go to GlyGen: P0DTC2-1

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
6m6 heavy chain	B [auth A], E [auth D], H [auth E], K [auth F], N [auth G], Q [auth H]	227	Homo sapiens	Mutation(s): 0

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
6m6 light chain	C, F [auth N], I [auth O], L [auth P], O [auth Q], R	214	Homo sapiens	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	AA [auth I], AB [auth L], BA [auth I], BB [auth L], CA [auth I], CB [auth L], DA [auth I], DB [auth L], EA [auth I], EB [auth L], FA [auth I], FB [auth M], GA [auth I], GB [auth M], HA [auth J], HB [auth M], IA [auth J], IB [auth M], JA [auth J], JB [auth M], KA [auth J], KB [auth M], LA [auth J], LB [auth M], MA [auth J], MB [auth M], NA [auth J], NB [auth M], OA [auth J], OB [auth M], PA [auth K], QA [auth K], RA [auth K], S [auth B], SA [auth K], T [auth B], TA [auth K], U [auth B], UA [auth K], V [auth B], VA [auth K], W [auth B], WA [auth L], X [auth B], XA [auth L], Y [auth B], YA [auth L], Z [auth I], ZA [auth L]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.34 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2022-07-13
Deposition Author(s): Zhan, W.Q., Zhang, X., Chen, Z.G., Sun, L.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	81900729

Revision History

• Version 1.0: 2022-07-13
  Type: Initial release

• Version 1.1: 2022-09-14
  Changes: Database references
• Version 1.2: 2024-10-16
  Changes: Data collection, Structure summary
• Version 1.3: 2025-07-02
  Changes: Data collection
