7VR6

Crystal structure of MlaC from Escherichia coli in quasi-open state


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.169
  • R-Value Observed: 0.171

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

MlaC belongs to a unique class of non-canonical substrate-binding proteins and follows a novel phospholipid-binding mechanism.

Dutta, A.Prasad Kanaujia, S.

(2022) J Struct Biol 214: 107896-107896

  • DOI: https://doi.org/10.1016/j.jsb.2022.107896
  • Primary Citation of Related Structures:
    7VR6

  • PubMed Abstract:

    The outer membrane (OM) of Gram-negative bacteria acts as a formidable barrier against a plethora of detrimental compounds owing to its asymmetric nature. This is because the OM possesses lipopolysaccharides (LPSs) in the outer leaflet and phospholipids (PLs) in the inner leaflet. The maintenance of lipid asymmetry (Mla) system is involved in preserving the distribution of PLs in OM. The periplasmic component of the system MlaC serves as the substrate-binding protein (SBP) that shuttles PLs between the inner and outer membranes. However, an in-depth report highlighting its mechanism of ligand binding is still lacking. This study reports the crystal structure of MlaC from Escherichia coli (EcMlaC) at a resolution of 2.5 Å in a quasi-open state, complexed with PL. The structural analysis reveals that EcMlaC and orthologs comprise two major domains, viz. nuclear transport factor 2-like (NTF2-like) and phospholipid-binding protein (PBP). Each domain can be further divided into two subdomains arranged in a discontinuous fashion. This study further reveals that EcMlaC is polyspecific in nature and follows a reverse mechanism of the opening of the substrate-binding site during the ligand binding. Furthermore, MlaC can bind two PLs by forming subsites in the binding pocket. These findings, altogether, have led to the proposition of the unique "segmented domain movement" mechanism of PL binding, not reported for any known SBP to date. Further, unlike typical SBPs, MlaC has originated from a cystatin-like fold. Overall, this study establishes MlaC to be a non-canonical SBP with a unique ligand-binding mechanism.


  • Organizational Affiliation

    Department of Biosciences and Bioengineering, Indian Institute of Technology Guwahati, Guwahati - 781039, Assam, India.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Intermembrane phospholipid transport system binding protein MlaC197Escherichia coli K-12Mutation(s): 0
Gene Names: mlaC
UniProt
Find proteins for P0ADV7 (Escherichia coli (strain K12))
Explore P0ADV7
Go to UniProtKB:  P0ADV7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADV7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PEF (Subject of Investigation/LOI)
Query on PEF

Download Ideal Coordinates CCD File
B [auth A]DI-PALMITOYL-3-SN-PHOSPHATIDYLETHANOLAMINE
C37 H74 N O8 P
SLKDGVPOSSLUAI-PGUFJCEWSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
C [auth A]1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Free: 0.217
  • R-Value Work: 0.169
  • R-Value Observed: 0.171
  • Space Group: H 3
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 114.94α = 90
b = 114.94β = 90
c = 46.1γ = 120
Software Package:
Software NamePurpose
HKL-3000data collection
Aimlessdata scaling
MOSFLMdata reduction
PHASERphasing
REFMACrefinement
Cootmodel building
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Science and Engineering Research Board (SERB)IndiaECR/2018/000013

Revision History  (Full details and data files)

  • Version 1.0: 2022-09-21
    Type: Initial release
  • Version 1.1: 2022-09-28
    Changes: Database references
  • Version 1.2: 2023-11-29
    Changes: Data collection, Refinement description
