7UKZ

CDK11 in complex with small molecule inhibitor OTS964


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.222
  • R-Value Observed: 0.245

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Crystal structure of the CDK11 kinase domain bound to the small-molecule inhibitor OTS964.

Kelso, S.O'Brien, S.Kurinov, I.Angers, S.Sicheri, F.

(2022) Structure 30: 1615

  • DOI: https://doi.org/10.1016/j.str.2022.10.003
  • Primary Citation of Related Structures:
    7UKZ

  • PubMed Abstract:

    CDK11 is a cyclin-dependent kinase that controls proliferation by regulating transcription, RNA splicing, and the cell cycle. As its activity is increasingly associated with cancer, CDK11 is an attractive target for the development of small-molecule inhibitors. However, the development of CDK11 inhibitors with limited off-target effects against other CDKs poses a challenge based on the high conservation of sequence across family members. OTS964 is notable as it displays a measure of specificity for CDK11 in cells. To understand the basis for OTS964's specificity for CDK11, we solved a 2.6 Å crystal structure of the CDK11 kinase domain bound to OTS964. Despite the absence of cyclin, CDK11 adopts an active-like conformation when bound to OTS964. We identified amino acids likely to contribute to the specificity of OTS964 for CDK11 and assessed their contribution to OTS964 binding by isothermal titration calorimetry (ITC) in vitro and by resistance to OTS964 in cells.


  • Organizational Affiliation

    Lunenfeld-Tanenbaum Research Institute, Sinai Health System, Toronto, ON M5G 1X5, Canada; Department of Molecular Genetics, University of Toronto, Toronto, ON M5S 1A8, Canada.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cyclin-dependent kinase 11B
A, B, C, D, E
A, B, C, D, E, F
319Homo sapiensMutation(s): 0
Gene Names: CDK11BCDC2L1CDK11PITSLREAPK58
EC: 2.7.11.22
UniProt & NIH Common Fund Data Resources
Find proteins for P21127 (Homo sapiens)
Explore P21127
Go to UniProtKB:  P21127
GTEx:  ENSG00000248333
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21127
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
NK3 (Subject of Investigation/LOI)
Query on NK3

Download Ideal Coordinates CCD File
G [auth A]
I [auth B]
K [auth C]
M [auth D]
O [auth E]
G [auth A],
I [auth B],
K [auth C],
M [auth D],
O [auth E],
Q [auth F]
OTS964
C23 H24 N2 O2 S
XCFRUAOZMVFDPQ-AWEZNQCLSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
H [auth A]
J [auth B]
L [auth C]
N [auth D]
P [auth E]
H [auth A],
J [auth B],
L [auth C],
N [auth D],
P [auth E],
R [auth F]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
TPO
Query on TPO
A, B, C, D, E
A, B, C, D, E, F
L-PEPTIDE LINKINGC4 H10 N O6 PTHR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.236
  • R-Value Work: 0.222
  • R-Value Observed: 0.245
  • Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 146.678α = 90
b = 146.678β = 90
c = 230.939γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata scaling
PHASERphasing
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Canadian Institutes of Health Research (CIHR)CanadaFDN-143277

Revision History  (Full details and data files)

  • Version 1.0: 2022-10-26
    Type: Initial release
  • Version 1.1: 2022-11-23
    Changes: Database references
  • Version 1.2: 2022-12-14
    Changes: Database references
  • Version 1.3: 2023-10-25
    Changes: Data collection, Refinement description
