7TXN

Reduced Structure of RexT


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.180
  • R-Value Observed: 0.184

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structural and mechanistic basis for redox sensing by the cyanobacterial transcription regulator RexT.

Li, B.Jo, M.Liu, J.Tian, J.Canfield, R.Bridwell-Rabb, J.

(2022) Commun Biol 5: 275-275

  • DOI: https://doi.org/10.1038/s42003-022-03226-x
  • Primary Citation of Related Structures:
    7TXM, 7TXN, 7TXO

  • PubMed Abstract:

    Organisms have a myriad of strategies for sensing, responding to, and combating reactive oxygen species, which are unavoidable consequences of aerobic life. In the heterocystous cyanobacterium Nostoc sp. PCC 7120, one such strategy is the use of an ArsR-SmtB transcriptional regulator RexT that senses H 2 O 2 and upregulates expression of thioredoxin to maintain cellular redox homeostasis. Different from many other members of the ArsR-SmtB family which bind metal ions, RexT has been proposed to use disulfide bond formation as a trigger to bind and release DNA. Here, we present high-resolution crystal structures of RexT in the reduced and H 2 O 2 -treated states. These structures reveal that RexT showcases the ArsR-SmtB winged-helix-turn-helix fold and forms a vicinal disulfide bond to orchestrate a response to H 2 O 2 . The importance of the disulfide-forming Cys residues was corroborated using site-directed mutagenesis, mass spectrometry, and H 2 O 2 -consumption assays. Furthermore, an entrance channel for H 2 O 2 was identified and key residues implicated in H 2 O 2 activation were pinpointed. Finally, bioinformatics analysis of the ArsR-SmtB family indicates that the vicinal disulfide "redox switch" is a unique feature of cyanobacteria in the Nostocales order, presenting an interesting case where an ArsR-SmtB protein scaffold has been evolved to showcase peroxidatic activity and facilitate redox-based regulation.


  • Organizational Affiliation

    Department of Chemistry, University of Michigan, Ann Arbor, MI, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Transcriptional regulator
A, B
114Nostoc sp. PCC 7120 = FACHB-418Mutation(s): 0
Gene Names: alr1867
UniProt
Find proteins for Q8YVV6 (Nostoc sp. (strain PCC 7120 / SAG 25.82 / UTEX 2576))
Explore Q8YVV6
Go to UniProtKB:  Q8YVV6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8YVV6
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GOL (Subject of Investigation/LOI)
Query on GOL

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
H [auth B]
I [auth B]
J [auth B]
E [auth A],
F [auth A],
H [auth B],
I [auth B],
J [auth B],
K [auth B],
L [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL (Subject of Investigation/LOI)
Query on CL

Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
G [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.95 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.180
  • R-Value Observed: 0.184
  • Space Group: P 64
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.891α = 90
b = 99.891β = 90
c = 36.472γ = 120
Software Package:
Software NamePurpose
XDSdata scaling
PHENIXrefinement
Cootmodel building
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Department of Energy (DOE, United States)United StatesDE-SC0021240

Revision History  (Full details and data files)

  • Version 1.0: 2022-03-23
    Type: Initial release
  • Version 1.1: 2022-04-13
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
