7T9V

Crystal structure of hSTING with the agonist, SHR171032


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.68 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.205
  • R-Value Observed: 0.207

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

SHR1032, a novel STING agonist, stimulates anti-tumor immunity and directly induces AML apoptosis.

Song, C.Liu, D.Liu, S.Li, D.Horecny, I.Zhang, X.Li, P.Chen, L.Miller, M.Chowdhury, R.Issa, M.Shen, R.Yan, Y.Zhang, F.Zhang, L.Zhang, L.Bai, C.Feng, J.Zhuang, L.Zhang, R.Li, J.Wilkinson, H.Liu, J.Tao, W.

(2022) Sci Rep 12: 8579-8579

  • DOI: https://doi.org/10.1038/s41598-022-12449-1
  • Primary Citation of Related Structures:
    7T9U, 7T9V

  • PubMed Abstract:

    Stimulator of interferon genes (STING) activation induces type I interferons and pro-inflammatory cytokines which stimulate tumor antigen cross presentation and the adaptive immune responses against tumor. The first-generation of STING agonists, cyclic di-nucleotide (CDN), mimicked the endogenous STING ligand cyclic guanosine monophosphate adenosine monophosphate, and displayed limited clinical efficacy. Here we report the discovery of SHR1032, a novel small molecule non-CDN STING agonist. Compared to the clinical CDN STING agonist ADU-S100, SHR1032 has much higher activity in human cells with different STING haplotypes and robustly induces interferon β (IFNβ) production. When dosed intratumorally, SHR1032 induced strong anti-tumor effects in the MC38 murine syngeneic tumor model. Pharmacodynamic studies showed induction of IFNβ, tumor necrosis factor α (TNFα) and interleukin-6 (IL-6) in the tumors and, to a lower extent, in the plasma. More importantly, we found SHR1032 directly causes cell death in acute myeloid leukemia (AML) cells. In conclusion, our findings demonstrate that in addition to their established ability to boost anti-tumor immune responses, STING agonists can directly eradicate AML cells, and SHR1032 may present a new and promising therapeutic agent for cancer patients.


  • Organizational Affiliation

    Eternity Bioscience Inc., 6 Cedarbrook Drive, Cranbury, NJ, 08512, USA. song_cy@hotmail.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Stimulator of interferon genes protein
A, B
198Homo sapiensMutation(s): 0
Gene Names: STING1ERISMITATMEM173
UniProt & NIH Common Fund Data Resources
Find proteins for Q86WV6 (Homo sapiens)
Explore Q86WV6
Go to UniProtKB:  Q86WV6
PHAROS:  Q86WV6
GTEx:  ENSG00000184584
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ86WV6
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GC0 (Subject of Investigation/LOI)
Query on GC0

Download Ideal Coordinates CCD File
D [auth A](3S,4S)-4-(3-{5-carbamoyl-2-[(1-ethyl-3-methyl-1H-pyrazole-5-carbonyl)amino]-7-methoxy-1H-benzimidazol-1-yl}propyl)-2-[(1-ethyl-3-methyl-1H-pyrazole-5-carbonyl)amino]-4,5-dihydroimidazo[1,5,4-de][1,4]benzoxazine-8-carboxamide
C36 H40 N12 O6
NXSXSRGBZKGELX-QFIPXVFZSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
C [auth A],
E [auth B]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.68 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.205
  • R-Value Observed: 0.207
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 91.307α = 90
b = 80.884β = 89.99
c = 73.13γ = 90
Software Package:
Software NamePurpose
SCALAdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-12-21
    Type: Initial release
  • Version 1.1: 2023-10-25
    Changes: Data collection, Refinement description
