7QZK

Crystal structure of mouse CNPase catalytic domain, V318I mutant

PDB DOI: https://doi.org/10.2210/pdb7QZK/pdb

Classification: HYDROLASE
Organism(s): Mus musculus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2022-01-31 Released: 2023-02-15
Deposition Author(s): Markusson, S., Kursula, P.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.66 Å
R-Value Free: 0.222
R-Value Work: 0.174
R-Value Observed: 0.179

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of mouse CNPase catalytic domain, V318I mutant

Markusson, S., Kursula, P.

To be published.

Macromolecule Content

Total Structure Weight: 24.5 kDa
Atom Count: 1,842
Modelled Residue Count: 213
Deposited Residue Count: 221
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2',3'-cyclic-nucleotide 3'-phosphodiesterase	A	221	Mus musculus	Mutation(s): 1 Gene Names: Cnp, Cnp1 EC: 3.1.4.37
UniProt & NIH Common Fund Data Resources
Find proteins for P16330 (Mus musculus) Explore P16330 Go to UniProtKB: P16330
IMPC: MGI:88437
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P16330
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CIT Query on CIT Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A]	B [auth A]	CITRIC ACID C₆ H₈ O₇ KRKNYBCHXYNGOX-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.66 Å
R-Value Free: 0.222
R-Value Work: 0.174
R-Value Observed: 0.179
Space Group: P 1 2₁ 1
Diffraction Data: https://doi.org/10.5281/zenodo.5323918

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 39.53	α = 90
b = 47.83	β = 97.21
c = 51.18	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2023-02-15

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-02-15
Type: Initial release
Version 1.1: 2024-02-07
Changes: Data collection, Refinement description
