7OXX

CrabP2 mutant R30AK31A

PDB DOI: https://doi.org/10.2210/pdb7OXX/pdb

Classification: TRANSPORT PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2021-06-23 Released: 2022-07-13
Deposition Author(s): Tomlinson, C.W.E., Basle, A., Pohl, E.
Funding Organization(s): Medical Research Council (MRC, United Kingdom)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.33 Å
R-Value Free: 0.200
R-Value Work: 0.158

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Structural requirements for the specific binding of CRABP2 to cyclin D3

Pastok, M.W., Tomlinson, C.W.E., Tatum, N.J., Basle, A., Noble, M.E.M., Pohl, E., Endicott, J.A.

To be published.

Macromolecule Content

Total Structure Weight: 62.37 kDa
Atom Count: 4,848
Modelled Residue Count: 549
Deposited Residue Count: 552
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cellular retinoic acid-binding protein 2	A, B, C, D	138	Homo sapiens	Mutation(s): 2 Gene Names: CRABP2
UniProt & NIH Common Fund Data Resources
Find proteins for P29373 (Homo sapiens) Explore P29373 Go to UniProtKB: P29373
PHAROS: P29373 GTEx: ENSG00000143320
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P29373
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth B] SDF format, chain G [auth C] SDF format, chain H [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth B] MOL2 format, chain G [auth C] MOL2 format, chain H [auth D]	E [auth A], F [auth B], G [auth C], H [auth D]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.33 Å
R-Value Free: 0.200
R-Value Work: 0.158
Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.17	α = 90
b = 106.02	β = 101.7
c = 55.54	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
xia2	data reduction
XDS	data reduction
Aimless	data scaling
PHASER	phasing
Coot	model building
MolProbity	model building

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2022-07-13

Deposition Author(s):

Tomlinson, C.W.E.

Funding Organization	Location	Grant Number
Medical Research Council (MRC, United Kingdom)	United Kingdom	MR/N009738/1

Revision History (Full details and data files)

Version 1.0: 2022-07-13
Type: Initial release
Version 1.1: 2024-01-31
Changes: Data collection, Refinement description
