7OWX

Structure of coiled-coil tetramer from SARS-CoV-2 spike stalk region


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.93 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.172
  • R-Value Observed: 0.178

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural polymorphism of coiled-coils from the stalk domain of SARS-CoV-2 spike protein.

Zivic, Z.Strmsek, Z.Novinec, M.Lah, J.Hadzi, S.

(2022) FASEB J 36: e22199-e22199

  • DOI: https://doi.org/10.1096/fj.202101670R
  • Primary Citation of Related Structures:
    7OWX

  • PubMed Abstract:

    Spike trimer plays a key role in SARS-CoV-2 infection and vaccine development. It consists of a globular head and a flexible stalk domain that anchors the protein into the viral membrane. While the head domain has been extensively studied, the properties of the adjoining stalk are poorly understood. Here, we characterize the coiled-coil formation and thermodynamic stability of the stalk domain and its segments. We find that the N-terminal segment of the stalk does not form coiled-coils and remains disordered in solution. The C-terminal stalk segment forms a trimeric coiled-coil in solution, which becomes significantly stabilized in the context of the full-length stalk. Its crystal structure reveals a novel antiparallel tetramer coiled-coil with an unusual combination of a-d and e-a-d hydrophobic core packing. Structural analysis shows that a subset of hydrophobic residues stabilizes different coiled-coil structures: trimer, tetramer, and heterohexamer, underscoring a highly polymorphic nature of the SARS-CoV-2 stalk sequence.


  • Organizational Affiliation

    Faculty of Chemistry and Chemical Technology, University of Ljubljana, Ljubljana, Slovenia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Spike protein S2
A, B, C, D
27Severe acute respiratory syndrome coronavirus 2Mutation(s): 1
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTC2
Go to UniProtKB:  P0DTC2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTC2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.93 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.172
  • R-Value Observed: 0.178
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.14α = 90
b = 45.54β = 90
c = 47.9γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling
Arcimboldophasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Slovenian Research AgencySloveniaJ1-1706
Slovenian Research AgencySloveniaP1-0201

Revision History  (Full details and data files)

  • Version 1.0: 2022-03-16
    Type: Initial release
