7MJJ

Cryo-EM structure of the SARS-CoV-2 N501Y mutant spike protein ectodomain bound to Fab ab1 (class 1)

PDB DOI: https://doi.org/10.2210/pdb7MJJ/pdb
EM Map EMD-23875: EMDB EMDataResource

Classification: VIRAL PROTEIN/Immune System
Organism(s): Severe acute respiratory syndrome coronavirus 2, synthetic construct
Expression System: Homo sapiens, Escherichia coli
Mutation(s): Yes

Deposited: 2021-04-20 Released: 2021-05-12
Deposition Author(s): Zhu, X., Mannar, D., Srivastava, S.S., Berezuk, A.M., Demers, J.P., Saville, J.W., Leopold, K., Li, W., Dimitrov, D.S., Tuttle, K.S., Zhou, S., Chittori, S., Subramaniam, S.
Funding Organization(s): Canada Excellence Research Chair Award, Other government

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.32 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Macromolecule Content

Total Structure Weight: 538.94 kDa
Atom Count: 31,680
Modelled Residue Count: 3,968
Deposited Residue Count: 4,780
Unique protein chains: 3

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,288	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 1 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTC2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Fab ab1 Heavy Chain	D, F	244	synthetic construct	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Fab ab1 Light Chain	E, G	214	synthetic construct	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	H, I, J, K, L H, I, J, K, L, M, N, O, P, Q, R, S, T, U, V, W, X, Y	2		N-Glycosylation	Interactions Focus chain H Focus chain I Focus chain J Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Focus chain V Focus chain W Focus chain X Focus chain Y Interactions & Density Focus chain H Focus chain I Focus chain J Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R Focus chain S Focus chain T Focus chain U Focus chain V Focus chain W Focus chain X Focus chain Y
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain AA [auth A] SDF format, chain BA [auth A] SDF format, chain FA [auth A] SDF format, chain GA [auth A] SDF format, chain JA [auth B] SDF format, chain LA [auth B] SDF format, chain OA [auth B] SDF format, chain PA [auth C] SDF format, chain UA [auth C] SDF format, chain WA [auth C] SDF format, chain CA [auth A] SDF format, chain DA [auth A] SDF format, chain EA [auth A] SDF format, chain HA [auth B] SDF format, chain IA [auth B] SDF format, chain KA [auth B] SDF format, chain MA [auth B] SDF format, chain NA [auth B] SDF format, chain QA [auth C] SDF format, chain RA [auth C] SDF format, chain SA [auth C] SDF format, chain TA [auth C] SDF format, chain VA [auth C] SDF format, chain Z [auth A] MOL2 format, chain AA [auth A] MOL2 format, chain BA [auth A] MOL2 format, chain FA [auth A] MOL2 format, chain GA [auth A] MOL2 format, chain JA [auth B] MOL2 format, chain LA [auth B] MOL2 format, chain OA [auth B] MOL2 format, chain PA [auth C] MOL2 format, chain UA [auth C] MOL2 format, chain WA [auth C] MOL2 format, chain CA [auth A] MOL2 format, chain DA [auth A] MOL2 format, chain EA [auth A] MOL2 format, chain HA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain KA [auth B] MOL2 format, chain MA [auth B] MOL2 format, chain NA [auth B] MOL2 format, chain QA [auth C] MOL2 format, chain RA [auth C] MOL2 format, chain SA [auth C] MOL2 format, chain TA [auth C] MOL2 format, chain VA [auth C] MOL2 format, chain Z [auth A]	AA [auth A] BA [auth A] CA [auth A] DA [auth A] EA [auth A] AA [auth A], BA [auth A], CA [auth A], DA [auth A], EA [auth A], FA [auth A], GA [auth A], HA [auth B], IA [auth B], JA [auth B], KA [auth B], LA [auth B], MA [auth B], NA [auth B], OA [auth B], PA [auth C], QA [auth C], RA [auth C], SA [auth C], TA [auth C], UA [auth C], VA [auth C], WA [auth C], Z [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth A] Focus chain BA [auth A] Focus chain CA [auth A] Focus chain DA [auth A] Focus chain EA [auth A] Focus chain FA [auth A] Focus chain GA [auth A] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Focus chain NA [auth B] Focus chain OA [auth B] Focus chain PA [auth C] Focus chain QA [auth C] Focus chain RA [auth C] Focus chain SA [auth C] Focus chain TA [auth C] Focus chain UA [auth C] Focus chain VA [auth C] Focus chain WA [auth C] Focus chain Z [auth A] Interactions & Density Focus chain AA [auth A] Focus chain BA [auth A] Focus chain CA [auth A] Focus chain DA [auth A] Focus chain EA [auth A] Focus chain FA [auth A] Focus chain GA [auth A] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Focus chain NA [auth B] Focus chain OA [auth B] Focus chain PA [auth C] Focus chain QA [auth C] Focus chain RA [auth C] Focus chain SA [auth C] Focus chain TA [auth C] Focus chain UA [auth C] Focus chain VA [auth C] Focus chain WA [auth C] Focus chain Z [auth A]
