7LGP | pdb_00007lgp

DapE enzyme from Shigella flexneri

PDB DOI: https://doi.org/10.2210/pdb7LGP/pdb

Classification: HYDROLASE
Organism(s): Shigella flexneri 2a str. 301
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2021-01-20 Released: 2021-01-27
Deposition Author(s): Osipiuk, J., Endres, M., Becker, D.P., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.91 Å
R-Value Free:
0.187 (Depositor), 0.190 (DCC)
R-Value Work:
0.159 (Depositor), 0.170 (DCC)
R-Value Observed:
0.160 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

DapE enzyme from Shigella flexneri

Osipiuk, J., Endres, M., Becker, D.P., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Macromolecule Content

Total Structure Weight: 83.9 kDa
Atom Count: 6,747
Modeled Residue Count: 751
Deposited Residue Count: 756
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Succinyl-diaminopimelate desuccinylase	A, B	378	Shigella flexneri 2a str. 301	Mutation(s): 0 Gene Names: dapE EC: 3.5.1.18
UniProt
Find proteins for P0AED8 (Shigella flexneri) Explore P0AED8 Go to UniProtKB: P0AED8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0AED8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain L [auth B] MOL2 format, chain C [auth A] MOL2 format, chain L [auth B] mmCIF format, chain C [auth A] mmCIF format, chain L [auth B]	C [auth A], L [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain L [auth B] Interactions & Density Focus chain C [auth A] Focus chain L [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain P [auth B] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain P [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain P [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain S [auth B] mmCIF format, chain T [auth B]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain U [auth B] SDF format, chain V [auth B] MOL2 format, chain K [auth A] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] mmCIF format, chain K [auth A] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B]	K [auth A], U [auth B], V [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain U [auth B] Focus chain V [auth B] Interactions & Density Focus chain K [auth A] Focus chain U [auth B] Focus chain V [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.91 Å
R-Value Free: 0.187 (Depositor), 0.190 (DCC)
R-Value Work: 0.159 (Depositor), 0.170 (DCC)
R-Value Observed: 0.160 (Depositor)

Diffraction Data: https://doi.org/10.18430/m37lgp

Space Group: H 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 180.141	α = 90
b = 180.141	β = 90
c = 200.091	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-3000	data scaling
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2021-01-27

Deposition Author(s):

Center for Structural Genomics of Infectious Diseases (CSGID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201200026C
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C
