7KWA

Structure of DCN1 bound to N-((4S,5S)-3-(aminomethyl)-7-ethyl-4-(4-fluorophenyl)-6-oxo-1-phenyl-4,5,6,7-tetrahydro-1H-pyrazolo[3,4-b]pyridin-5-yl)-3-(trifluoromethyl)benzamide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.57 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.170
  • R-Value Observed: 0.171

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Improvement of Oral Bioavailability of Pyrazolo-Pyridone Inhibitors of the Interaction of DCN1/2 and UBE2M.

Kim, H.S.Hammill, J.T.Scott, D.C.Chen, Y.Rice, A.L.Pistel, W.Singh, B.Schulman, B.A.Guy, R.K.

(2021) J Med Chem 64: 5850-5862

  • DOI: https://doi.org/10.1021/acs.jmedchem.1c00035
  • Primary Citation of Related Structures:
    7KWA

  • PubMed Abstract:

    The cullin-RING ubiquitin ligases (CRLs) are ubiquitin E3 enzymes that play a key role in controlling proteasomal degradation and are activated by neddylation. We previously reported inhibitors that target CRL activation by disrupting the interaction of defective in cullin neddylation 1 (DCN1), a CRL neddylation co-E3, and UBE2M, a neddylation E2. Our first-generation inhibitors possessed poor oral bioavailability and fairly rapid clearance that hindered the study of acute inhibition of DCN-controlled CRL activity in vivo. Herein, we report studies to improve the pharmacokinetic performance of the pyrazolo-pyridone inhibitors. The current best inhibitor, 40 , inhibits the interaction of DCN1 and UBE2M, blocks NEDD8 transfer in biochemical assays, thermally stabilizes cellular DCN1, and inhibits anchorage-independent growth in a DCN1 amplified squamous cell carcinoma cell line. Additionally, we demonstrate that a single oral 50 mg/kg dose sustains plasma exposures above the biochemical IC 90 for 24 h in mice.


  • Organizational Affiliation

    Department of Pharmaceutical Sciences, University of Kentucky, Lexington, Kentucky 40508, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Endolysin,DCN1-like protein 1384Enterobacteria phage RB59Homo sapiens
This entity is chimeric
Mutation(s): 0
Gene Names: eRB59_126DCUN1D1DCN1DCUN1L1RP42SCCRO
EC: 3.2.1.17
UniProt & NIH Common Fund Data Resources
Find proteins for A0A097J809 (Enterobacteria phage RB59)
Explore A0A097J809
Go to UniProtKB:  A0A097J809
Find proteins for Q96GG9 (Homo sapiens)
Explore Q96GG9
Go to UniProtKB:  Q96GG9
PHAROS:  Q96GG9
GTEx:  ENSG00000043093
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsA0A097J809Q96GG9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
YHP (Subject of Investigation/LOI)
Query on YHP

Download Ideal Coordinates CCD File
B [auth A]N-[(4S,5S)-3-(aminomethyl)-7-ethyl-4-(4-fluorophenyl)-6-oxo-1-phenyl-4,5,6,7-tetrahydro-1H-pyrazolo[3,4-b]pyridin-5-yl]-3-(trifluoromethyl)benzamide
C29 H25 F4 N5 O2
QEHZKPQZGREGTJ-ZCYQVOJMSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
YHP BindingDB:  7KWA IC50: 110 (nM) from 1 assay(s)
EC50: 300 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.57 Å
  • R-Value Free: 0.209
  • R-Value Work: 0.170
  • R-Value Observed: 0.171
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 35.233α = 90
b = 97.057β = 106.11
c = 59.837γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
PDB_EXTRACTdata extraction
HKL-2000data reduction
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United States5R01CA247365-02

Revision History  (Full details and data files)

  • Version 1.0: 2021-07-14
    Type: Initial release
  • Version 1.1: 2023-10-18
    Changes: Data collection, Database references, Refinement description
