7F01 | pdb_00007f01

Structure of a triple-helix region of human collagen type XVII

PDB DOI: https://doi.org/10.2210/pdb7F01/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Homo sapiens
Mutation(s): No

Deposited: 2021-06-03 Released: 2022-06-08
Deposition Author(s): Zhu, Y., Yang, X., Sun, F.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.63 Å
R-Value Free:
0.242 (Depositor), 0.243 (DCC)
R-Value Work:
0.217 (Depositor), 0.217 (DCC)
R-Value Observed:
0.220 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7F01

This is version 1.1 of the entry. See complete history.

Literature

Structure of a triple-helix region of human collagen type XVII

Zhu, Y., Yang, X., Sun, F.

To be published.

Macromolecule Content

Total Structure Weight: 8.08 kDa
Atom Count: 697
Modeled Residue Count: 87
Deposited Residue Count: 87
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
collagen type XVII	A, B, C	29	Homo sapiens	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth B] MOL2 format, chain D [auth B] mmCIF format, chain D [auth B]	D [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth B] Interactions & Density Focus chain D [auth B]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
HYP Query on HYP	A, B, C	L-PEPTIDE LINKING	C₅ H₉ N O₃		PRO

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.63 Å
R-Value Free: 0.242 (Depositor), 0.243 (DCC)
R-Value Work: 0.217 (Depositor), 0.217 (DCC)
R-Value Observed: 0.220 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 20.32	α = 90
b = 21.26	β = 90.38
c = 67.6	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
BALBES	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2022-06-08

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2022-06-08
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection, Refinement description
