Crystal structure of VIM1 PHD finger.

Experimental Data Snapshot

  • Resolution: 2.61 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.215
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Helical and beta-Turn Conformations in the Peptide Recognition Regions of the VIM1 PHD Finger Abrogate H3K4 Peptide Recognition.

Abhishek, S.Deeksha, W.Rajakumara, E.

(2021) Biochemistry 60: 2652-2662

  • DOI: https://doi.org/10.1021/acs.biochem.1c00191
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The PHD finger-containing VARIANT IN METHYLATION/ORTHRUS (VIM/ORTH) family of proteins in Arabidopsis consists of functional homologues of mammalian UHRF1 and is required for the maintenance of DNA methylation. Comparison of the sequence with those of other PHD fingers implied that VIM1 and VIM3 PHD could recognize lysine 4 of histone H3 (H3K4) through interactions mediated by a conserved aspartic acid. However, our calorimetric and modified histone peptide array binding studies suggested that neither H3K4 nor other histone marks are recognized by VIM1 and VIM3 PHD fingers. Here, we report a 2.6 Å resolution crystal structure of the VIM1 PHD finger and demonstrate significant structural changes in the putative H3 recognition segments in contrast to canonical H3K4 binding PHD fingers. These changes include (i) the H3A1 binding region, (ii) strand β1 that forms an intermolecular β-sheet with the H3 peptide, and (iii) an aspartate-containing motif involved in salt bridge interaction with H3K4, which together appear to abrogate recognition of H3K4 by the VIM1 PHD finger. To understand the significance of the altered structural features in the VIM1 PHD that might prevent histone H3 recognition, we modeled a chimeric VIM1 PHD (chmVIM1 PHD) by grafting the peptide binding structural features of the BHC80 PHD onto the VIM1 PHD. Molecular dynamics simulation and metadynamics analyses revealed that the chmVIM1 PHD-H3 complex is stable and also showed a network of intermolecular interactions similar to those of the BHC80 PHD-H3 complex. Collectively, this study reveals that subtle structural changes in the peptide binding region of the VIM1 PHD abrogate histone H3 recognition.

  • Organizational Affiliation

    Macromolecular Structural Biology Lab, Department of Biotechnology, Indian Institute of Technology Hyderabad, Kandi, Sangareddy, Telangana 502285, India.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase ORTHRUS 2
A, B
67Arabidopsis thalianaMutation(s): 0
Gene Names: ORTH2VIM1At1g57820F12K22.14
Find proteins for Q8VYZ0 (Arabidopsis thaliana)
Explore Q8VYZ0
Go to UniProtKB:  Q8VYZ0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8VYZ0
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.61 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.215
  • R-Value Observed: 0.216
  • Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.59α = 90
b = 74.59β = 90
c = 58.88γ = 120
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
Cootmodel building

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2021-08-25
    Type: Initial release
  • Version 1.1: 2022-02-16
    Changes: Database references
  • Version 1.2: 2024-05-29
    Changes: Data collection
