6ZTJ

E. coli 70S-RNAP expressome complex in NusG-coupled state (38 nt intervening mRNA)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report

Currently 6ZTJ does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Structural basis of transcription-translation coupling and collision in bacteria.

Webster, M.W.Takacs, M.Zhu, C.Vidmar, V.Eduljee, A.Abdelkareem, M.Weixlbaumer, A.

(2020) Science 369: 1355-1359

  • DOI: https://doi.org/10.1126/science.abb5036
  • Primary Citation of Related Structures:
    6ZTJ, 6ZTL, 6ZTM, 6ZTN, 6ZTO, 6ZTP, 6ZU1

  • PubMed Abstract:

    Prokaryotic messenger RNAs (mRNAs) are translated as they are transcribed. The lead ribosome potentially contacts RNA polymerase (RNAP) and forms a supramolecular complex known as the expressome. The basis of expressome assembly and its consequences for transcription and translation are poorly understood. Here, we present a series of structures representing uncoupled, coupled, and collided expressome states determined by cryo-electron microscopy. A bridge between the ribosome and RNAP can be formed by the transcription factor NusG, which stabilizes an otherwise-variable interaction interface. Shortening of the intervening mRNA causes a substantial rearrangement that aligns the ribosome entrance channel to the RNAP exit channel. In this collided complex, NusG linkage is no longer possible. These structures reveal mechanisms of coordination between transcription and translation and provide a framework for future study.


  • Organizational Affiliation

    Department of Integrated Structural Biology, Institut de Génétique et de Biologie Moléculaire et Cellulaire (IGBMC), 67404 Illkirch, France.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S2B [auth AB]241Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7V0 (Escherichia coli (strain K12))
Explore P0A7V0
Go to UniProtKB:  P0A7V0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S3C [auth AC]233Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7V3 (Escherichia coli (strain K12))
Explore P0A7V3
Go to UniProtKB:  P0A7V3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S4D [auth AD]206Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7V8 (Escherichia coli (strain K12))
Explore P0A7V8
Go to UniProtKB:  P0A7V8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S5E [auth AE]167Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7W1 (Escherichia coli (strain K12))
Explore P0A7W1
Go to UniProtKB:  P0A7W1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7W1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S6F [auth AF]131Escherichia coliMutation(s): 0
UniProt
Find proteins for P02358 (Escherichia coli (strain K12))
Explore P02358
Go to UniProtKB:  P02358
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02358
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S7G [auth AG]156Escherichia coliMutation(s): 0
UniProt
Find proteins for P02359 (Escherichia coli (strain K12))
Explore P02359
Go to UniProtKB:  P02359
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02359
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S8H [auth AH]130Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7W7 (Escherichia coli (strain K12))
Explore P0A7W7
Go to UniProtKB:  P0A7W7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7W7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S9I [auth AI]130Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7X3 (Escherichia coli (strain K12))
Explore P0A7X3
Go to UniProtKB:  P0A7X3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7X3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S10J [auth AJ]103Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7R5 (Escherichia coli (strain K12))
Explore P0A7R5
Go to UniProtKB:  P0A7R5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S11K [auth AK]129Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7R9 (Escherichia coli (strain K12))
Explore P0A7R9
Go to UniProtKB:  P0A7R9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S12L [auth AL]124Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7S3 (Escherichia coli (strain K12))
Explore P0A7S3
Go to UniProtKB:  P0A7S3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7S3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S13M [auth AM]118Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7S9 (Escherichia coli (strain K12))
Explore P0A7S9
Go to UniProtKB:  P0A7S9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7S9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S14N [auth AN]101Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG59 (Escherichia coli (strain K12))
Explore P0AG59
Go to UniProtKB:  P0AG59
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG59
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S15O [auth AO]89Escherichia coliMutation(s): 0
UniProt
Find proteins for P0ADZ4 (Escherichia coli (strain K12))
Explore P0ADZ4
Go to UniProtKB:  P0ADZ4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADZ4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S16P [auth AP]82Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7T3 (Escherichia coli (strain K12))
Explore P0A7T3
Go to UniProtKB:  P0A7T3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7T3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S17Q [auth AQ]84Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG63 (Escherichia coli (strain K12))
Explore P0AG63
Go to UniProtKB:  P0AG63
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG63
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S18R [auth AR]75Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7T7 (Escherichia coli (strain K12))
Explore P0A7T7
Go to UniProtKB:  P0A7T7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7T7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S19S [auth AS]92Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7U3 (Escherichia coli (strain K12))
Explore P0A7U3
Go to UniProtKB:  P0A7U3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7U3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S20T [auth AT]87Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7U7 (Escherichia coli (strain K12))
Explore P0A7U7
Go to UniProtKB:  P0A7U7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7U7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 21
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S21U [auth AU]71Escherichia coliMutation(s): 0
UniProt
Find proteins for P68679 (Escherichia coli (strain K12))
Explore P68679
Go to UniProtKB:  P68679
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68679
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 25
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S1Y [auth AY]557Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG67 (Escherichia coli (strain K12))
Explore P0AG67
Go to UniProtKB:  P0AG67
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG67
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 28
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L2BA [auth BC]273Escherichia coliMutation(s): 0
UniProt
Find proteins for P60422 (Escherichia coli (strain K12))
Explore P60422
Go to UniProtKB:  P60422
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60422
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 29
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L3CA [auth BD]209Escherichia coliMutation(s): 0
UniProt
Find proteins for P60438 (Escherichia coli (strain K12))
Explore P60438
Go to UniProtKB:  P60438
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60438
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 30
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L4DA [auth BE]201Escherichia coliMutation(s): 0
UniProt
Find proteins for P60723 (Escherichia coli (strain K12))
Explore P60723
Go to UniProtKB:  P60723
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60723
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 31
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L5EA [auth BF]179Escherichia coliMutation(s): 0
UniProt
Find proteins for P62399 (Escherichia coli (strain K12))
Explore P62399
Go to UniProtKB:  P62399
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62399
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 32
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L6FA [auth BG]177Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG55 (Escherichia coli (strain K12))
Explore P0AG55
Go to UniProtKB:  P0AG55
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG55
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 33
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L9GA [auth BH]149Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7R1 (Escherichia coli (strain K12))
Explore P0A7R1
Go to UniProtKB:  P0A7R1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 34
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L10HA [auth BI]165Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7J3 (Escherichia coli (strain K12))
Explore P0A7J3
Go to UniProtKB:  P0A7J3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7J3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 35
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L11IA [auth BJ]142Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7J7 (Escherichia coli (strain K12))
Explore P0A7J7
Go to UniProtKB:  P0A7J7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7J7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 36
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L13JA [auth BK]142Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AA10 (Escherichia coli (strain K12))
Explore P0AA10
Go to UniProtKB:  P0AA10
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AA10
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 37
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L14KA [auth BL]123Escherichia coliMutation(s): 0
UniProt
Find proteins for P0ADY3 (Escherichia coli (strain K12))
Explore P0ADY3
Go to UniProtKB:  P0ADY3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADY3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 38
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L15LA [auth BM]144Escherichia coliMutation(s): 0
UniProt
Find proteins for P02413 (Escherichia coli (strain K12))
Explore P02413
Go to UniProtKB:  P02413
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02413
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 39
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L16MA [auth BN]136Escherichia coliMutation(s): 0
UniProt
Find proteins for P0ADY7 (Escherichia coli (strain K12))
Explore P0ADY7
Go to UniProtKB:  P0ADY7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADY7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 40
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L17NA [auth BO]127Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG44 (Escherichia coli (strain K12))
Explore P0AG44
Go to UniProtKB:  P0AG44
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG44
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 41
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L18OA [auth BP]117Escherichia coliMutation(s): 0
UniProt
Find proteins for P0C018 (Escherichia coli (strain K12))
Explore P0C018
Go to UniProtKB:  P0C018
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C018
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 42
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L19PA [auth BQ]115Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7K6 (Escherichia coli (strain K12))
Explore P0A7K6
Go to UniProtKB:  P0A7K6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7K6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 43
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L20QA [auth BR]118Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7L3 (Escherichia coli (strain K12))
Explore P0A7L3
Go to UniProtKB:  P0A7L3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7L3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 44
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L21RA [auth BS]103Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG48 (Escherichia coli (strain K12))
Explore P0AG48
Go to UniProtKB:  P0AG48
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG48
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 45
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L22SA [auth BT]110Escherichia coliMutation(s): 0
UniProt
Find proteins for P61175 (Escherichia coli (strain K12))
Explore P61175
Go to UniProtKB:  P61175
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP61175
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 46
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L23TA [auth BU]100Escherichia coliMutation(s): 0
UniProt
Find proteins for P0ADZ0 (Escherichia coli (strain K12))
Explore P0ADZ0
Go to UniProtKB:  P0ADZ0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADZ0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 47
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L24UA [auth BV]104Escherichia coliMutation(s): 0
UniProt
Find proteins for P60624 (Escherichia coli (strain K12))
Explore P60624
Go to UniProtKB:  P60624
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60624
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 48
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L25VA [auth BW]94Escherichia coliMutation(s): 0
UniProt
Find proteins for P68919 (Escherichia coli (strain K12))
Explore P68919
Go to UniProtKB:  P68919
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68919
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 49
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L27WA [auth BX]85Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7L8 (Escherichia coli (strain K12))
Explore P0A7L8
Go to UniProtKB:  P0A7L8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7L8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 50
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L28XA [auth BY]78Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7M2 (Escherichia coli (strain K12))
Explore P0A7M2
Go to UniProtKB:  P0A7M2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7M2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 51
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L29YA [auth BZ]63Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7M6 (Escherichia coli (strain K12))
Explore P0A7M6
Go to UniProtKB:  P0A7M6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7M6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 52
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L30ZA [auth B1]59Escherichia coliMutation(s): 0
UniProt
Find proteins for P0AG51 (Escherichia coli (strain K12))
Explore P0AG51
Go to UniProtKB:  P0AG51
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG51
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 53
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L32AB [auth B2]57Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7N4 (Escherichia coli (strain K12))
Explore P0A7N4
Go to UniProtKB:  P0A7N4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7N4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 54
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L33BB [auth B3]55Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7N9 (Escherichia coli (strain K12))
Explore P0A7N9
Go to UniProtKB:  P0A7N9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7N9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 55
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L34CB [auth B4]46Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7P5 (Escherichia coli (strain K12))
Explore P0A7P5
Go to UniProtKB:  P0A7P5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7P5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 56
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L35DB [auth B5]65Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7Q1 (Escherichia coli (strain K12))
Explore P0A7Q1
Go to UniProtKB:  P0A7Q1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7Q1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 57
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L36EB [auth B6]50Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7Q6 (Escherichia coli (strain K12))
Explore P0A7Q6
Go to UniProtKB:  P0A7Q6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7Q6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 58
MoleculeChains Sequence LengthOrganismDetailsImage
50S ribosomal protein L31FB [auth B7]70Escherichia coliMutation(s): 0
UniProt
Find proteins for P0A7M9 (Escherichia coli (strain K12))
Explore P0A7M9
Go to UniProtKB:  P0A7M9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7M9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 61
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit alphaIB [auth CA],
JB [auth CB]
329Escherichia coliMutation(s): 0
Gene Names: rpoApezphssezb3295JW3257
EC: 2.7.7.6
UniProt
Find proteins for P0A7Z4 (Escherichia coli (strain K12))
Explore P0A7Z4
Go to UniProtKB:  P0A7Z4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7Z4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 62
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit betaKB [auth CC]1,342Escherichia coliMutation(s): 0
Gene Names: rpoBZ5560ECs4910
EC: 2.7.7.6
UniProt
Find proteins for P0A8V2 (Escherichia coli (strain K12))
Explore P0A8V2
Go to UniProtKB:  P0A8V2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A8V2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 63
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta'LB [auth CD]1,407Escherichia coliMutation(s): 0
Gene Names: rpoCZ5561ECs4911
EC: 2.7.7.6
UniProt
Find proteins for P0A8T7 (Escherichia coli (strain K12))
Explore P0A8T7
Go to UniProtKB:  P0A8T7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A8T7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 64
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit omegaMB [auth CE]91Escherichia coliMutation(s): 0
Gene Names: rpoZb3649JW3624
EC: 2.7.7.6
UniProt
Find proteins for P0A800 (Escherichia coli (strain K12))
Explore P0A800
Go to UniProtKB:  P0A800
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A800
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 65
MoleculeChains Sequence LengthOrganismDetailsImage
Transcription termination/antitermination protein NusGNB [auth CF]181Escherichia coliMutation(s): 0
Gene Names: nusGZ5555ECs4905
UniProt
Find proteins for P0AFG0 (Escherichia coli (strain K12))
Explore P0AFG0
Go to UniProtKB:  P0AFG0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AFG0
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
16S ribosomal RNAA [auth AA]1,542Escherichia coli
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 22
MoleculeChains LengthOrganismImage
mRNAV [auth AV]53synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 23
MoleculeChains LengthOrganismImage
tRNA(fmet) P-siteW [auth AW]77Escherichia coli
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 24
MoleculeChains LengthOrganismImage
Phe-NH-tRNA(Phe) A-siteX [auth AX]76Escherichia coli
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 26
MoleculeChains LengthOrganismImage
23S ribosomal RNAZ [auth BA]2,904Escherichia coli
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 27
MoleculeChains LengthOrganismImage
5S ribosomal RNAAA [auth BB]120Escherichia coli
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 59
MoleculeChains LengthOrganismImage
Non-template DNA strandGB [auth CN]39synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 60
MoleculeChains LengthOrganismImage
Template DNA strandHB [auth CT]39synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PHE
Query on PHE

Download Ideal Coordinates CCD File
IH [auth AX]PHENYLALANINE
C9 H11 N O2
COLNVLDHVKWLRT-QMMMGPOBSA-N
ZN
Query on ZN

Download Ideal Coordinates CCD File
AU [auth B7],
CU [auth CD],
DU [auth CD],
ZT [auth B6]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
