6V51

Spin-labeled T4 Lysozyme (9/131FnbY)-(4-Amino-TEMPO)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.184
  • R-Value Work: 0.168

wwPDB Validation   3D Report Full Report

Currently 6V51 does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Genetically Encoded Quinone Methides Enabling Rapid, Site-Specific, and Photocontrolled Protein Modification with Amine Reagents.

Liu, J.Cheng, R.Van Eps, N.Wang, N.Morizumi, T.Ou, W.L.Klauser, P.C.Rozovsky, S.Ernst, O.P.Wang, L.

(2020) J Am Chem Soc 142: 17057-17068

  • DOI: https://doi.org/10.1021/jacs.0c06820
  • Primary Citation of Related Structures:
    6V51

  • PubMed Abstract:

    Site-specific modification of proteins with functional molecules provides powerful tools for researching and engineering proteins. Here we report a new chemical conjugation method which photocages highly reactive but chemically selective moieties, enabling the use of protein-inert amines for selective protein modification. New amino acids FnbY and FmnbY, bearing photocaged quinone methides (QMs), were genetically incorporated into proteins. Upon light activation, they generated highly reactive QM, which rapidly reacted with amine derivatives. This method features a rare combination of desired properties including fast kinetics, small and stable linkage, compatibility with low temperature, photocontrollability, and widely available reagents. Moreover, labeling via FnbY occurs on the β-carbon, affording the shortest linkage to protein backbone which is essential for advanced studies involving orientation and distance. We installed various functionalities onto proteins and attached a spin label as close as possible to the protein backbone, achieving high resolution in double electron-electron paramagnetic resonance distance measurements.


  • Organizational Affiliation

    Department of Pharmaceutical Chemistry and the Cardiovascular Research Institute, University of California San Francisco, 555 Mission Bay Blvd. South, San Francisco, California 94158, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Endolysin164Tequatrovirus T4Mutation(s): 0
Gene Names: eT4Tp126
EC: 3.2.1.17
UniProt
Find proteins for D9IEF7 (Enterobacteria phage T4)
Explore D9IEF7
Go to UniProtKB:  D9IEF7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupD9IEF7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.184
  • R-Value Work: 0.168
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 59.407α = 90
b = 59.407β = 90
c = 95.489γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report

Currently 6V51 does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM118384
Natural Sciences and Engineering Research Council (NSERC, Canada)CanadaRGPIN-2017-06862
Canada Excellence Research Chair AwardCanada--
National Science Foundation (NSF, United States)United StatesMCB-1616178

Revision History  (Full details and data files)

  • Version 1.0: 2020-10-07
    Type: Initial release
  • Version 1.1: 2020-10-21
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
