6DKQ

Crystal structure of the Shr Hemoglobin Interacting Domain 2

  • Classification: TRANSPORT PROTEIN
  • Organism(s): Streptococcus pyogenes
  • Expression System: Escherichia coli BL21(DE3)
  • Mutation(s): No

  • Deposited: 2018-05-30 Released: 2018-10-24
  • Deposition Author(s): Macdonald, R., Cascio, D., Collazo, M.J., Clubb, R.T.
  • Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), Department of Energy (DOE, United States), National Science Foundation (NSF, United States), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.197
  • R-Value Observed: 0.198

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

The Streptococcus pyogenes Shr protein captures human hemoglobin using two structurally unique binding domains.

Macdonald, R.Cascio, D.Collazo, M.J.Phillips, M.Clubb, R.T.

(2018) J Biol Chem 293: 18365-18377

  • DOI: https://doi.org/10.1074/jbc.RA118.005261
  • Primary Citation of Related Structures:
    6DKQ

  • PubMed Abstract:

    In order to proliferate and mount an infection, many bacterial pathogens need to acquire iron from their host. The most abundant iron source in the body is the oxygen transporter hemoglobin (Hb). Streptococcus pyogenes , a potentially lethal human pathogen, uses the Shr protein to capture Hb on the cell surface. Shr is an important virulence factor, yet the mechanism by which it captures Hb and acquires its heme is not well-understood. Here, we show using NMR and biochemical methods that Shr binds Hb using two related modules that were previously defined as domains of unknown function (DUF1533). These hemoglobin-interacting domains (HIDs), called HID1 and HID2, are autonomously folded and independently bind Hb. The 1.5 Å resolution crystal structure of HID2 revealed that it is a structurally unique Hb-binding domain. Mutagenesis studies revealed a conserved tyrosine in both HIDs that is essential for Hb binding. Our biochemical studies indicate that HID2 binds Hb with higher affinity than HID1 and that the Hb tetramer is engaged by two Shr receptors. NMR studies reveal the presence of a third autonomously folded domain between HID2 and a heme-binding NEAT1 domain, suggesting that this linker domain may position NEAT1 near Hb for heme capture.


  • Organizational Affiliation

    From the Department of Chemistry and Biochemistry,; UCLA-DOE Institute of Genomics and Proteomics and.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Heme-binding protein Shr
A, B
112Streptococcus pyogenesMutation(s): 0
Gene Names: shr
UniProt
Find proteins for B0LFQ8 (Streptococcus pyogenes)
Explore B0LFQ8
Go to UniProtKB:  B0LFQ8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB0LFQ8
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.222
  • R-Value Work: 0.197
  • R-Value Observed: 0.198
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 32.47α = 90
b = 59.14β = 90
c = 102.71γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
PHASERphasing
BUSTERrefinement
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI52217
Department of Energy (DOE, United States)United StatesDE-FC02-02ER63421
National Science Foundation (NSF, United States)United StatesMCB-1716948
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM007185

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-24
    Type: Initial release
  • Version 1.1: 2019-05-15
    Changes: Data collection, Database references
  • Version 1.2: 2019-05-22
    Changes: Data collection, Database references
  • Version 1.3: 2019-11-27
    Changes: Author supporting evidence
  • Version 1.4: 2024-03-13
    Changes: Data collection, Database references
