6YYI | pdb_00006yyi

Crystal structure of beta-D-xylosidase from Dictyoglomus thermophilum bound to beta-D-xylopyranose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.67 Å
  • R-Value Free:
    0.227 (Depositor), 0.229 (DCC)
  • R-Value Work:
    0.177 (Depositor), 0.182 (DCC)
  • R-Value Observed:
    0.180 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6YYI

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Crystal structure of Dictyoglomus thermophilum beta-d-xylosidase DtXyl unravels the structural determinants for efficient notoginsenoside R1 hydrolysis.

Bretagne, D.Paris, A.de Vaumas, R.Lafite, P.Daniellou, R.

(2020) Biochimie 181: 34-41

  • DOI: https://doi.org/10.1016/j.biochi.2020.11.017
  • Primary Citation Related Structures:
    6YYH, 6YYI

  • PubMed Abstract:

    Dictyoglomus thermophilum β-d-xylosidase DtXyl is attractive as a potential thermostable biocatalyst able to produce biologically active ginsenosides intermediates from β-(1,2)-D-xylosylated compounds, including Notoginsenoside-R1. DtXyl was expressed as an active N-terminal His-tagged protein, and its crystal structure was solved in presence or absence of d-xylose product. Modelling of notoginsenoside R1 in DtXyl active site led to the identification of several hydrophobic residues interacting in close contact to the substrate hydrophobic core. Unlike other residues involved in substrate binding, these residues are not conserved among GH39 xylosidase family, and their physico-chemical properties can be correlated to the efficient binding and subsequent hydrolysis of Notoginsenoside R1.


  • Organizational Affiliation
    • Institut de Chimie Organique et Analytique (ICOA), UMR CNRS-Université d'Orléans 7311, Université d'Orléans, BP 6759, Orléans, 45067, Cedex 2, France.

Macromolecule Content

  • Total Structure Weight: 123.74 kDa
  • Atom Count: 8,480
  • Modeled Residue Count: 1,004
  • Deposited Residue Count: 1,048
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-xylosidase
A, B
524Dictyoglomus thermophilum H-6-12Mutation(s): 0
Gene Names: DICTH_1792
EC: 3.2.1.37
UniProt
Find proteins for B5YB78 (Dictyoglomus thermophilum (strain ATCC 35947 / DSM 3960 / H-6-12))
Explore B5YB78
Go to UniProtKB:  B5YB78
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB5YB78
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CIT

Query on CIT



Download:Ideal Coordinates CCD File
G [auth A]CITRIC ACID
C6 H8 O7
KRKNYBCHXYNGOX-UHFFFAOYSA-N
XYP
(Subject of Investigation/LOI)

Query on XYP



Download:Ideal Coordinates CCD File
P [auth B]beta-D-xylopyranose
C5 H10 O5
SRBFZHDQGSBBOR-KKQCNMDGSA-N
SO4

Query on SO4



Download:Ideal Coordinates CCD File
K [auth A],
R [auth B]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
EDO

Query on EDO



Download:Ideal Coordinates CCD File
C [auth A]
D [auth A]
E [auth A]
F [auth A]
H [auth A]
C [auth A],
D [auth A],
E [auth A],
F [auth A],
H [auth A],
I [auth A],
J [auth A],
L [auth B],
M [auth B],
N [auth B],
O [auth B],
Q [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
NA

Query on NA



Download:Ideal Coordinates CCD File
S [auth B],
T [auth B]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.67 Å
  • R-Value Free:  0.227 (Depositor), 0.229 (DCC)
  • R-Value Work:  0.177 (Depositor), 0.182 (DCC)
  • R-Value Observed: 0.180 (Depositor)
Space Group: P 31 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 160.95α = 90
b = 160.95β = 90
c = 103.63γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-12-02
    Type: Initial release
  • Version 1.1: 2020-12-09
    Changes: Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
