6VGD

Crystal structure of the DNA binding domain (DBD) of human FLI1 and the complex of the DBD of human Runx2 with core binding factor beta (Cbfb), in complex with 16mer DNA CAGAGGATGTGGCTTC

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.20 Å
  • R-Value Free: 0.293
  • R-Value Work: 0.295
  • R-Value Observed: 0.295

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Allosteric interference in oncogenic FLI1 and ERG transactions by mithramycins.

Hou, C., Mandal, A., Rohr, J., Tsodikov, O.V.

(2021) Structure 29: 404-412.e4

  • DOI: https://doi.org/10.1016/j.str.2020.11.012
  • Primary Citation of Related Structures:
    6VG2, 6VG8, 6VGD, 6VGE, 6VGG

  • PubMed Abstract:

    • ETS family transcription factors of ERG and FLI1 play a key role in oncogenesis of prostate cancer and Ewing sarcoma by binding regulatory DNA sites and interfering with function of other factors. Mithramycin (MTM) is an anti-cancer, DNA binding natural product that functions as a potent antagonist of ERG and FLI1 by an unknown mechanism ...

    ETS family transcription factors of ERG and FLI1 play a key role in oncogenesis of prostate cancer and Ewing sarcoma by binding regulatory DNA sites and interfering with function of other factors. Mithramycin (MTM) is an anti-cancer, DNA binding natural product that functions as a potent antagonist of ERG and FLI1 by an unknown mechanism. We present a series of crystal structures of the DNA binding domain (DBD) of ERG/FLI1 culminating in a structure of a high-order complex of the ERG/FLI1 DBD, transcription factor Runx2, core-binding factor beta (Cbfβ), and MTM on a DNA enhancer site, along with supporting DNA binding studies using MTM and its analogues. Taken together, these data provide insight into allosteric mechanisms underlying ERG and FLI1 transactions and their disruption by MTM analogues.

    Organizational Affiliation:

    Department of Pharmaceutical Sciences, College of Pharmacy, University of Kentucky, Lexington, KY 40536, USA. Electronic address: oleg.tsodikov@uky.edu.



Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Friend leukemia integration 1 transcription factorA104Homo sapiensMutation(s): 0
Gene Names: FLI1
UniProt & NIH Common Fund Data Resources
Find proteins for Q01543 (Homo sapiens)
Explore Q01543
Go to UniProtKB:  Q01543
PHAROS:  Q01543
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ01543
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Runt-related transcription factor 2D177Homo sapiensMutation(s): 0
Gene Names: RUNX2, AML3, CBFA1, OSF2, PEBP2A
UniProt & NIH Common Fund Data Resources
Find proteins for Q13950 (Homo sapiens)
Explore Q13950
Go to UniProtKB:  Q13950
PHAROS:  Q13950
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13950
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Core-binding factor subunit betaE [auth G]156Homo sapiensMutation(s): 0
Gene Names: CBFB
UniProt & NIH Common Fund Data Resources
Find proteins for Q13951 (Homo sapiens)
Explore Q13951
Go to UniProtKB:  Q13951
PHAROS:  Q13951
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13951
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsLengthOrganismImage
DNA (5'-D(P*CP*AP*GP*AP*GP*GP*AP*TP*GP*TP*GP*GP*CP*TP*TP*C)-3')B16Homo sapiens
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChainsLengthOrganismImage
DNA (5'-D(P*GP*AP*AP*GP*CP*CP*AP*CP*AP*TP*CP*CP*TP*CP*TP*G)-3')C16Homo sapiens
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.20 Å
  • R-Value Free: 0.293
  • R-Value Work: 0.295
  • R-Value Observed: 0.295
  • Space Group: P 62 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 104.513α = 90
b = 104.513β = 90
c = 322.04γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Department of Defense (DOD, United States)United StatesPC150300P1
Department of Defense (DOD, United States)United StatesPC150300P2

Revision History  (Full details and data files)

  • Version 1.0: 2020-11-25
    Type: Initial release
  • Version 1.1: 2020-12-16
    Changes: Database references
  • Version 1.2: 2021-05-19
    Changes: Database references
