6VFB

DNA Polymerase Mu, 8-oxorGTP:Ct Reaction State Ternary Complex, 50 mM Mn2+ (960 min)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.181
  • R-Value Work: 0.167
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

DNA Polymerase Mu, 8-oxorGTP:Ct Reaction State Ternary Complex, 50 mM Mn2+ (960 min)

Jamsen, J.A.Sassa, A.Shock, D.D.Beard, W.A.Wilson, S.H.

To be published.

Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
DNA-directed DNA/RNA polymerase muA356Homo sapiensMutation(s): 0
Gene Names: POLMpolmu
EC: 2.7.7.7
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NP87 (Homo sapiens)
Explore Q9NP87
Go to UniProtKB:  Q9NP87
PHAROS:  Q9NP87
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NP87
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsLengthOrganismImage
DNA (5'-D(*CP*GP*GP*CP*CP*TP*AP*CP*G)-3')B [auth T]9synthetic construct
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChainsLengthOrganismImage
DNA (5'-D(*CP*GP*TP*AP*(8GM))-3')C [auth P]5synthetic construct
Protein Feature View
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 4
MoleculeChainsLengthOrganismImage
DNA (5'-D(P*GP*CP*CP*G)-3')D4synthetic construct
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 7 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
8GT (Subject of Investigation/LOI)
Query on 8GT

Download Ideal Coordinates CCD File
N [auth A]8-OXO-GUANOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O15 P3
JCHLKIQZUXYLPW-UMMCILCDSA-N
 Ligand Interaction
EPE
Query on EPE

Download Ideal Coordinates CCD File
M [auth A]4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID
C8 H18 N2 O4 S
JKMHFZQWWAIEOD-UHFFFAOYSA-N
 Ligand Interaction
PPV (Subject of Investigation/LOI)
Query on PPV

Download Ideal Coordinates CCD File
P [auth A]PYROPHOSPHATE
H4 O7 P2
XPPKVPWEQAFLFU-UHFFFAOYSA-N
 Ligand Interaction
DTT
Query on DTT

Download Ideal Coordinates CCD File
O [auth A]2,3-DIHYDROXY-1,4-DITHIOBUTANE
C4 H10 O2 S2
VHJLVAABSRFDPM-IMJSIDKUSA-N
 Ligand Interaction
EDO
Query on EDO

Download Ideal Coordinates CCD File
E [auth A],
F [auth A],
G [auth A],
H [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
 Ligand Interaction
MN (Subject of Investigation/LOI)
Query on MN

Download Ideal Coordinates CCD File
I [auth A],
J [auth A],
K [auth A],
Q [auth T],
R [auth P],
I [auth A],
J [auth A],
K [auth A],
Q [auth T],
R [auth P],
S [auth P],
T [auth D]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
 Ligand Interaction
NA
Query on NA

Download Ideal Coordinates CCD File
L [auth A]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.181
  • R-Value Work: 0.167
  • R-Value Observed: 0.168
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.198α = 90
b = 62.334β = 90
c = 118.756γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PDB_EXTRACTdata extraction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesZ01-ES050158
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesZ01-10ES050161
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United States1K99ES029572-01
Japan Society for the Promotion of Science (JSPS)Japan16K16195

Revision History  (Full details and data files)

  • Version 1.0: 2021-09-01
    Type: Initial release
