6UVK | pdb_00006uvk

OXA-48 bound by inhibitor CDD-97


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.223 (Depositor), 0.223 (DCC)
  • R-Value Work:
    0.184 (Depositor), 0.185 (DCC)
  • R-Value Observed:
    0.186 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6UVK

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Identifying Oxacillinase-48 Carbapenemase Inhibitors Using DNA-Encoded Chemical Libraries.

Taylor, D.M.Anglin, J.Park, S.Ucisik, M.N.Faver, J.C.Simmons, N.Jin, Z.Palaniappan, M.Nyshadham, P.Li, F.Campbell, J.Hu, L.Sankaran, B.Prasad, B.V.V.Huang, H.Matzuk, M.M.Palzkill, T.

(2020) ACS Infect Dis 6: 1214-1227

  • DOI: https://doi.org/10.1021/acsinfecdis.0c00015
  • Primary Citation Related Structures:
    6UVK

  • PubMed Abstract:

    Bacterial resistance to β-lactam antibiotics is largely mediated by β-lactamases, which catalyze the hydrolysis of these drugs and continue to emerge in response to antibiotic use. β-Lactamases that hydrolyze the last resort carbapenem class of β-lactam antibiotics (carbapenemases) are a growing global health threat. Inhibitors have been developed to prevent β-lactamase-mediated hydrolysis and restore the efficacy of these antibiotics. However, there are few inhibitors available for problematic carbapenemases such as oxacillinase-48 (OXA-48). A DNA-encoded chemical library approach was used to rapidly screen for compounds that bind and potentially inhibit OXA-48. Using this approach, a hit compound, CDD-97, was identified with submicromolar potency ( K i = 0.53 ± 0.08 μM) against OXA-48. X-ray crystallography showed that CDD-97 binds noncovalently in the active site of OXA-48. Synthesis and testing of derivatives of CDD-97 revealed structure-activity relationships and informed the design of a compound with a 2-fold increase in potency. CDD-97, however, synergizes poorly with β-lactam antibiotics to inhibit the growth of bacteria expressing OXA-48 due to poor accumulation into E. coli . Despite the low in vivo activity, CDD-97 provides new insights into OXA-48 inhibition and demonstrates the potential of using DNA-encoded chemistry technology to rapidly identify β-lactamase binders and to study β-lactamase inhibition, leading to clinically useful inhibitors.


  • Organizational Affiliation
    • Verna and Marrs McLean Department of Biochemistry and Molecular Biology, Baylor College of Medicine, Houston, Texas 77030, United States.

Macromolecule Content

  • Total Structure Weight: 115.15 kDa
  • Atom Count: 8,453
  • Modeled Residue Count: 968
  • Deposited Residue Count: 976
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Beta-lactamase
A, B, C, D
244Klebsiella pneumoniaeMutation(s): 0
Gene Names: bla OXA-48blaOXA-48FNY87_29090KPE71T_00045
EC: 3.5.2.6
UniProt
Find proteins for Q6XEC0 (Klebsiella pneumoniae)
Explore Q6XEC0
Go to UniProtKB:  Q6XEC0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6XEC0
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
QHY
(Subject of Investigation/LOI)

Query on QHY



Download:Ideal Coordinates CCD File
E [auth A],
G [auth B],
I [auth C],
L [auth D]
1-{4-[4-(2-ethoxyphenyl)piperazin-1-yl]-1,3,5-triazin-2-yl}piperidine-4-carboxylic acid
C21 H28 N6 O3
MFDIQEKYAZCUMU-UHFFFAOYSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
J [auth C]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
F [auth A],
H [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
K [auth C],
M [auth D],
N [auth D]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
KCX
Query on KCX
A, B, C, D
L-PEPTIDE LINKINGC7 H14 N2 O4LYS

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.223 (Depositor), 0.223 (DCC)
  • R-Value Work:  0.184 (Depositor), 0.185 (DCC)
  • R-Value Observed: 0.186 (Depositor)
Space Group: P 65
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 123.054α = 90
b = 123.054β = 90
c = 161.329γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesAI32956
Department of Energy (DOE, United States)United StatesDE-AC02-05CH11231
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesT32GM120011

Revision History  (Full details and data files)

  • Version 1.0: 2020-05-06
    Type: Initial release
  • Version 1.1: 2020-05-20
    Changes: Database references
  • Version 1.2: 2021-06-30
    Changes: Structure summary
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
  • Version 1.4: 2023-11-15
    Changes: Data collection
