6UVH

Crystal structure of BCL-XL bound to compound 15: (R)-2-(3-(2-((4'-Chloro-[1,1'-biphenyl]-2-yl)methyl)-1,2,3,4-tetrahydroisoquinoline-6-carbonyl)-3-(4-methylbenzyl)ureido)-3-((cyclohexylmethyl)sulfonyl)propanoic acid


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.207
  • R-Value Observed: 0.208

wwPDB Validation   3D Report Full Report

Currently 6UVH does not have a validation slider image.


This is version 1.3 of the entry. See complete history


Literature

Structure-Guided Development of Potent Benzoylurea Inhibitors of BCL-X L and BCL-2.

Roy, M.J.Vom, A.Okamoto, T.Smith, B.J.Birkinshaw, R.W.Yang, H.Abdo, H.White, C.A.Segal, D.Huang, D.C.S.Baell, J.B.Colman, P.M.Czabotar, P.E.Lessene, G.

(2021) J Med Chem 64: 5447-5469

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c01771
  • Primary Citation of Related Structures:
    6UVC, 6UVD, 6UVE, 6UVF, 6UVG, 6UVH

  • PubMed Abstract:

    The BCL-2 family of proteins (including the prosurvival proteins BCL-2, BCL-X L , and MCL-1) is an important target for the development of novel anticancer therapeutics. Despite the challenges of targeting protein-protein interaction (PPI) interfaces with small molecules, a number of inhibitors (called BH3 mimetics) have entered the clinic and the BCL-2 inhibitor, ABT-199/venetoclax, is already proving transformative. For BCL-X L , new validated chemical series are desirable. Here, we outline the crystallography-guided development of a structurally distinct series of BCL-X L /BCL-2 inhibitors based on a benzoylurea scaffold, originally proposed as α-helix mimetics. We describe structure-guided exploration of a cryptic "p5" pocket identified in BCL-X L . This work yields novel inhibitors with submicromolar binding, with marked selectivity toward BCL-X L . Extension into the hydrophobic p2 pocket yielded the most potent inhibitor in the series, binding strongly to BCL-X L and BCL-2 (nanomolar-range half-maximal inhibitory concentration (IC 50 )) and displaying mechanism-based killing in cells engineered to depend on BCL-X L for survival.


  • Organizational Affiliation

    The Walter and Eliza Hall Institute of Medical Research, 1G Royal Parade, Parkville, VIC 3052, Australia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bcl-2-like protein 1
A, B, C, D
158Homo sapiensMutation(s): 0
Gene Names: BCL2L1BCL2LBCLX
UniProt & NIH Common Fund Data Resources
Find proteins for Q07817 (Homo sapiens)
Explore Q07817
Go to UniProtKB:  Q07817
PHAROS:  Q07817
GTEx:  ENSG00000171552
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ07817
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
QHJ (Subject of Investigation/LOI)
Query on QHJ

Download Ideal Coordinates CCD File
G [auth A],
H [auth B],
I [auth C],
K [auth D]
(R)-2-(3-(2-((4'-Chloro-[1,1'-biphenyl]-2-yl)methyl)-1,2,3,4-tetrahydroisoquinoline-6-carbonyl)-3-(4-methylbenzyl)ureido)-3-((cyclohexylmethyl)sulfonyl)propanoic acid
C42 H46 Cl N3 O6 S
GZCIVAADWCIZJC-KDXMTYKHSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
F [auth A],
J [auth D]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
EDO
Query on EDO

Download Ideal Coordinates CCD File
E [auth A]1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.207
  • R-Value Observed: 0.208
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 152.026α = 90
b = 65.931β = 98.71
c = 77.133γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
XSCALEdata scaling
PHASERphasing
BUSTERrefinement
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report

Currently 6UVH does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Health and Medical Research Council (NHMRC, Australia)Australia--

Revision History  (Full details and data files)

  • Version 1.0: 2021-05-05
    Type: Initial release
  • Version 1.1: 2021-05-12
    Changes: Database references
  • Version 1.2: 2021-05-26
    Changes: Database references
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
