6U8J | pdb_00006u8j

Crystal structure of 3-deoxy-D-arabinoheptulosonate-7-phosphate synthase/phospho-2-dehydro-3-deoxyheptonate aldolase (Aro3) from Candida auris

• PDB DOI: https://doi.org/10.2210/pdb6U8J/pdb

• Classification: TRANSFERASE
• Organism(s): Candidozyma auris
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2019-09-05 Released: 2019-09-18
• Deposition Author(s): Michalska, K., Evdokimova, E., Semper, C., Di Leo, R., Stogios, P.J., Savchenko, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.49 Å
• R-Value Free:
  0.229 (Depositor), 0.232 (DCC)
• R-Value Work:
  0.184 (Depositor), 0.186 (DCC)
• R-Value Observed:
  0.186 (Depositor)

Starting Model: experimental

Literature

Crystal structure of 3-deoxy-D-arabinoheptulosonate-7-phosphate synthase/phospho-2-dehydro-3-deoxyheptonate aldolase (Aro3) from Candida auris

Michalska, K., Evdokimova, E., Semper, C., Di Leo, R., Stogios, P.J., Savchenko, A., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 329.38 kDa
• Atom Count: 22,717
• Modeled Residue Count: 2,957
• Deposited Residue Count: 3,008
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phospho-2-dehydro-3-deoxyheptonate aldolase	A, B, C, D, E, F, G, H	376	Candidozyma auris	Mutation(s): 0  Gene Names: B9J08_002185 EC: 2.5.1.54
UniProt
Find proteins for A0A2H0ZWN3 (Candidozyma auris) Explore A0A2H0ZWN3  Go to UniProtKB:  A0A2H0ZWN3

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
UNX	I [auth A], J [auth B], K [auth C], L [auth D]	UNKNOWN ATOM OR ION X

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.49 Å
• R-Value Free:  0.229 (Depositor), 0.232 (DCC)
• R-Value Work:  0.184 (Depositor), 0.186 (DCC)
• R-Value Observed: 0.186 (Depositor)

Diffraction Data: https://doi.org/10.18430/m36u8j

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.504	α = 90
b = 141.348	β = 97.92
c = 192.872	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
SBC-Collect	data collection

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2019-09-18
Deposition Author(s): Michalska, K., Evdokimova, E., Semper, C., Di Leo, R., Stogios, P.J., Savchenko, A., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History

• Version 1.0: 2019-09-18
  Type: Initial release

• Version 1.1: 2019-12-18
  Changes: Author supporting evidence
• Version 1.2: 2023-10-11
  Changes: Data collection, Database references, Refinement description
