6S9M

Designed Armadillo Repeat protein Lock2 fused to target peptide KRKRKAKITW


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.177
  • R-Value Observed: 0.179

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structure-Guided Design of a Peptide Lock for Modular Peptide Binders.

Ernst, P.Zosel, F.Reichen, C.Nettels, D.Schuler, B.Pluckthun, A.

(2020) ACS Chem Biol 15: 457-468

  • DOI: https://doi.org/10.1021/acschembio.9b00928
  • Primary Citation of Related Structures:
    6S9L, 6S9M, 6S9N, 6S9O, 6S9P

  • PubMed Abstract:

    Peptides play an important role in intermolecular interactions and are frequent analytes in diagnostic assays, also as unstructured, linear epitopes in whole proteins. Yet, due to the many different sequence possibilities even for short peptides, classical selection of binding proteins from a library, one at a time, is not scalable to proteomes. However, moving away from selection to a rational assembly of preselected modules binding to predefined linear epitopes would split the problem into smaller parts. These modules could then be reassembled in any desired order to bind to, in principle, arbitrary sequences, thereby circumventing any new rounds of selection. Designed Armadillo repeat proteins (dArmRPs) are modular, and they do bind elongated peptides in a modular way. Their consensus sequence carries pockets that prefer arginine and lysine. In our quest to select pockets for all amino acid side chains, we had discovered that repetitive sequences can lead to register shifts and peptide flipping during selections from libraries, hindering the selection of new binding specificities. To solve this problem, we now created an orthogonal binding specificity by a combination of grafting from β-catenin, computational design and mutual optimization of the pocket and the bound peptide. We have confirmed the design and the desired interactions by X-ray structure determination. Furthermore, we could confirm the absence of sliding in solution by a single-molecule Förster resonance energy transfer. The new pocket could be moved from the N-terminus of the protein to the middle, retaining its properties, further underlining the modularity of the system.


  • Organizational Affiliation

    Department of Biochemistry , University Zürich , Winterthurerstrasse 190 , 8057 Zürich , Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Lock2_KRKRKAKITW
A, B, C, D, E
A, B, C, D, E, F
302synthetic constructMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PG4
Query on PG4

Download Ideal Coordinates CCD File
GA [auth D],
KA [auth E],
LA [auth E]
TETRAETHYLENE GLYCOL
C8 H18 O5
UWHCKJMYHZGTIT-UHFFFAOYSA-N
PGE
Query on PGE

Download Ideal Coordinates CCD File
AA [auth C],
HA [auth D],
MA [auth E]
TRIETHYLENE GLYCOL
C6 H14 O4
ZIBGPFATKBEMQZ-UHFFFAOYSA-N
EDO
Query on EDO

Download Ideal Coordinates CCD File
EA [auth D]
FA [auth D]
IA [auth E]
JA [auth E]
K [auth A]
EA [auth D],
FA [auth D],
IA [auth E],
JA [auth E],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
QA [auth F],
V [auth B],
W [auth B],
X [auth B],
Y [auth B]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
BA [auth D]
CA [auth D]
DA [auth D]
G [auth A]
H [auth A]
BA [auth D],
CA [auth D],
DA [auth D],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
NA [auth F],
O [auth A],
OA [auth F],
P [auth A],
PA [auth F],
Q [auth B],
R [auth B],
S [auth B],
T [auth B],
U [auth B],
Z [auth B]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.177
  • R-Value Observed: 0.179
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 54.853α = 90
b = 85.474β = 96.32
c = 193.97γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2020-02-19
    Type: Initial release
  • Version 1.1: 2020-03-04
    Changes: Database references
