6S05

Cryo-EM structures of Lsg1-TAP pre-60S ribosomal particles


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.9 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Mechanism of completion of peptidyltransferase centre assembly in eukaryotes.

Kargas, V.Castro-Hartmann, P.Escudero-Urquijo, N.Dent, K.Hilcenko, C.Sailer, C.Zisser, G.Marques-Carvalho, M.J.Pellegrino, S.Wawiorka, L.Freund, S.M.Wagstaff, J.L.Andreeva, A.Faille, A.Chen, E.Stengel, F.Bergler, H.Warren, A.J.

(2019) Elife 8: --

  • DOI: 10.7554/eLife.44904
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • During their final maturation in the cytoplasm, pre-60S ribosomal particles are converted to translation-competent large ribosomal subunits. Here, we present the mechanism of peptidyltransferase centre (PTC) completion that explains how integration o ...

    During their final maturation in the cytoplasm, pre-60S ribosomal particles are converted to translation-competent large ribosomal subunits. Here, we present the mechanism of peptidyltransferase centre (PTC) completion that explains how integration of the last ribosomal proteins is coupled to release of the nuclear export adaptor Nmd3. Single-particle cryo-EM reveals that eL40 recruitment stabilises helix 89 to form the uL16 binding site. The loading of uL16 unhooks helix 38 from Nmd3 to adopt its mature conformation. In turn, partial retraction of the L1 stalk is coupled to a conformational switch in Nmd3 that allows the uL16 P-site loop to fully accommodate into the PTC where it competes with Nmd3 for an overlapping binding site (base A2971). Our data reveal how the central functional site of the ribosome is sculpted and suggest how the formation of translation-competent 60S subunits is disrupted in leukaemia-associated ribosomopathies.


    Organizational Affiliation

    Department of Molecular Biology, Maria Curie-Skłodowska University, Lublin, Poland.,Department of Biology, University of Konstanz, Konstanz, Germany.,Cambridge Institute for Medical Research, Cambridge, United Kingdom.,Department of Haematology, University of Cambridge, Cambridge, United Kingdom.,Faculty of Biological Sciences, University of Leeds, Leeds, United Kingdom.,Wellcome Trust-Medical Research Council Stem Cell Institute, University of Cambridge, Cambridge, United Kingdom.,Institute of Molecular Biosciences, University of Graz, Graz, Austria.,MRC Laboratory of Molecular Biology, Cambridge, United Kingdom.




Macromolecules

Find similar proteins by: Sequence  |  Structure


Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L2-A
B
254Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL2A (RPL5B)
Find proteins for P0CX45 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX45
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L3
C
387Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL3 (MAK8, TCM1)
Find proteins for P14126 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL3
Go to UniProtKB:  P14126
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L4-A
D
362Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL4A (RPL2, RPL2A)
Find proteins for P10664 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P10664
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L11-A
E
174Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL11A (RP39A, RPL16A)
Find proteins for P0C0W9 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0C0W9
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L9-A
F
191Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL9A (RPL8A, RPL9)
Find proteins for P05738 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05738
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L6-A
G
176Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL6A (RPL17A, YL16A)
Find proteins for Q02326 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02326
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L8-A
H
256Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL8A (MAK7, RPL4A)
Find proteins for P17076 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P17076
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L16-B
J
198Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL16B (RP23, RPL21B)
Find proteins for P26785 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P26785
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L13-A
K
199Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL13A
Find proteins for Q12690 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL13A
Go to UniProtKB:  Q12690
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L23-A
L
137Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL23A (RPL17A, RPL17AA)
Find proteins for P0CX41 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL23A
Go to UniProtKB:  P0CX41
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L14-A
M
138Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL14A
Find proteins for P36105 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P36105
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L28
N
149Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL28 (CYH2)
Find proteins for P02406 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL28
Go to UniProtKB:  P02406
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L15-A
O
204Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL15A (RPL10A, RPL13A, YL10A)
Find proteins for P05748 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05748
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L5
P
297Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL5 (RPL1, RPL1A)
Find proteins for P26321 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL5
Go to UniProtKB:  P26321
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L18-A
Q
186Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL18A (RP28A)
Find proteins for P0CX49 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL18A
Go to UniProtKB:  P0CX49
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L19-A
R
189Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL19A (RPL23A, YL14A)
Find proteins for P0CX82 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX82
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L20-A
S
172Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL20A (RPL18A, RPL18A2)
Find proteins for P0CX23 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX23
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L21-A
T
160Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL21A (URP1)
Find proteins for Q02753 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02753
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L17-A
U
184Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL17A (RPL17, RPL20A)
Find proteins for P05740 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05740
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L22-A
V
121Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL22A
Find proteins for P05749 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05749
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L25
W
142Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL25
Find proteins for P04456 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04456
Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L26-A
X
127Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL26A (RPL26, RPL33A)
Find proteins for P05743 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05743
Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L27-A
Y
136Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL27A (RPL27)
Find proteins for P0C2H6 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL27A
Go to UniProtKB:  P0C2H6
Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L35-A
Z
120Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL35A (SOS1)
Find proteins for P0CX84 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL35A
Go to UniProtKB:  P0CX84
Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L29
a
59Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL29 (YL43)
Find proteins for P05747 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL29
Go to UniProtKB:  P05747
Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L7-A
b
244Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL7A (RPL6A, RPL8A, YL8A)
Find proteins for P05737 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL7A
Go to UniProtKB:  P05737
Entity ID: 28
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L30
c
105Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL30 (RPL32)
Find proteins for P14120 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL30
Go to UniProtKB:  P14120
Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L31-A
d
113Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL31A (RPL34, RPL34A)
Find proteins for P0C2H8 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0C2H8
Entity ID: 30
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L32
e
130Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL32
Find proteins for P38061 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL32
Go to UniProtKB:  P38061
Entity ID: 31
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L33-A
f
107Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL33A (RPL37A)
Find proteins for P05744 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05744
Entity ID: 32
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L34-A
g
121Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL34A
Find proteins for P87262 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P87262
Entity ID: 33
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L36-A
h
100Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL36A (RPL39A)
Find proteins for P05745 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL36A
Go to UniProtKB:  P05745
Entity ID: 34
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L37-A
i
88Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL37A (RPL35A)
Find proteins for P49166 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL37A
Go to UniProtKB:  P49166
Entity ID: 35
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L38
j
78Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL38
Find proteins for P49167 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL38
Go to UniProtKB:  P49167
Entity ID: 36
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L39
k
51Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL39 (RPL46, SPB2)
Find proteins for P04650 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: RPL39
Go to UniProtKB:  P04650
Entity ID: 37
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L42-A
l
106Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL42A (RPL41A, SCL41A)
Find proteins for P0CX27 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX27
Entity ID: 38
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L43-A
m
92Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL43A
Find proteins for P0CX25 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX25
Entity ID: 39
MoleculeChainsSequence LengthOrganismDetails
Eukaryotic translation initiation factor 6
n
245Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: TIF6 (CDC95)
Find proteins for Q12522 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q12522
Entity ID: 40
MoleculeChainsSequence LengthOrganismDetails
Cytoplasmic 60S subunit biogenesis factor REH1
z
432Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: REH1
Find proteins for Q06709 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q06709
Entity ID: 41
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal export protein NMD3
w
518Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: NMD3
Find proteins for P38861 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: NMD3
Go to UniProtKB:  P38861
Entity ID: 42
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L24-A
v
155Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: RPL24A (RP29, RPL30A)
Find proteins for P04449 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04449
Entity ID: 43
MoleculeChainsSequence LengthOrganismDetails
Large subunit GTPase 1
o
640Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: LSG1
EC: 3.6.1.-
Find proteins for P53145 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to Gene View: LSG1
Go to UniProtKB:  P53145
Entity ID: 44
MoleculeChainsSequence LengthOrganismDetails
uL1
p
210N/AMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Entity ID: 45
MoleculeChainsSequence LengthOrganismDetails
Tyrosine-protein phosphatase YVH1
s
364Saccharomyces cerevisiae (strain ATCC 204508 / S288c)Mutation(s): 0
Gene Names: YVH1
EC: 3.1.3.48
Find proteins for Q02256 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02256
Entity ID: 1
MoleculeChainsLengthOrganism
25S ribosomal RNAA3396Saccharomyces cerevisiae
Entity ID: 46
MoleculeChainsLengthOrganism
5S ribosomal RNAx121Saccharomyces cerevisiae
Entity ID: 47
MoleculeChainsLengthOrganism
5.8S ribosomal RNAy158Saccharomyces cerevisiae
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download SDF File
Download CCD File
g, i, l, m, s, w
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
UNK
Query on UNK
p
L-PEPTIDE LINKINGC4 H9 N O2

--

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.9 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
BloodwiseUnited Kingdom12048
Medical Research Council (United Kingdom)United Kingdom105161083

Revision History

  • Version 1.0: 2019-06-26
    Type: Initial release
  • Version 1.1: 2019-07-10
    Type: Data collection, Database references
