6QIK

Cryo-EM structures of Lsg1-TAP pre-60S ribosomal particles


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Mechanism of completion of peptidyltransferase centre assembly in eukaryotes.

Kargas, V.Castro-Hartmann, P.Escudero-Urquijo, N.Dent, K.Hilcenko, C.Sailer, C.Zisser, G.Marques-Carvalho, M.J.Pellegrino, S.Wawiorka, L.Freund, S.M.Wagstaff, J.L.Andreeva, A.Faille, A.Chen, E.Stengel, F.Bergler, H.Warren, A.J.

(2019) Elife 8

  • DOI: 10.7554/eLife.44904
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • During their final maturation in the cytoplasm, pre-60S ribosomal particles are converted to translation-competent large ribosomal subunits. Here, we present the mechanism of peptidyltransferase centre (PTC) completion that explains how integration o ...

    During their final maturation in the cytoplasm, pre-60S ribosomal particles are converted to translation-competent large ribosomal subunits. Here, we present the mechanism of peptidyltransferase centre (PTC) completion that explains how integration of the last ribosomal proteins is coupled to release of the nuclear export adaptor Nmd3. Single-particle cryo-EM reveals that eL40 recruitment stabilises helix 89 to form the uL16 binding site. The loading of uL16 unhooks helix 38 from Nmd3 to adopt its mature conformation. In turn, partial retraction of the L1 stalk is coupled to a conformational switch in Nmd3 that allows the uL16 P-site loop to fully accommodate into the PTC where it competes with Nmd3 for an overlapping binding site (base A2971). Our data reveal how the central functional site of the ribosome is sculpted and suggest how the formation of translation-competent 60S subunits is disrupted in leukaemia-associated ribosomopathies.


    Organizational Affiliation

    Wellcome Trust-Medical Research Council Stem Cell Institute, University of Cambridge, Cambridge, United Kingdom.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L2-A
B
254Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX45 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX45

Find similar proteins by: Sequence  |  Structure

Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L3
C
387Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P14126 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P14126

Find similar proteins by: Sequence  |  Structure

Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L4-A
D
362Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P10664 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P10664

Find similar proteins by: Sequence  |  Structure

Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L11-A
E
174Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0C0W9 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0C0W9

Find similar proteins by: Sequence  |  Structure

Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L9-A
F
191Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05738 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05738

Find similar proteins by: Sequence  |  Structure

Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L6-A
G
176Saccharomyces cerevisiaeMutation(s): 0
Find proteins for Q02326 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02326

Find similar proteins by: Sequence  |  Structure

Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L16-B
J
198Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P26785 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P26785

Find similar proteins by: Sequence  |  Structure

Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L13-A
K
199Saccharomyces cerevisiaeMutation(s): 0
Find proteins for Q12690 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q12690

Find similar proteins by: Sequence  |  Structure

Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L23-A
L
137Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX41 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX41

Find similar proteins by: Sequence  |  Structure

Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L14-A
M
138Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P36105 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P36105

Find similar proteins by: Sequence  |  Structure

Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L28
N
149Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P02406 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P02406

Find similar proteins by: Sequence  |  Structure

Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L15-A
O
204Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05748 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05748

Find similar proteins by: Sequence  |  Structure

Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L5
P
297Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P26321 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P26321

Find similar proteins by: Sequence  |  Structure

Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L18-A
Q
186Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX49 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX49

Find similar proteins by: Sequence  |  Structure

Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L19-A
R
189Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX82 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX82

Find similar proteins by: Sequence  |  Structure

Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L20-A
S
172Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX23 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX23

Find similar proteins by: Sequence  |  Structure

Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L21-A
T
160Saccharomyces cerevisiaeMutation(s): 0
Find proteins for Q02753 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q02753

Find similar proteins by: Sequence  |  Structure

Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L17-A
U
154Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05740 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05740

Find similar proteins by: Sequence  |  Structure

Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L22-A
V
121Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05749 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05749

Find similar proteins by: Sequence  |  Structure

Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L25
W
142Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P04456 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04456

Find similar proteins by: Sequence  |  Structure

Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L26-A
X
127Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05743 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05743

Find similar proteins by: Sequence  |  Structure

Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L35-A
Z
120Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX84 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX84

Find similar proteins by: Sequence  |  Structure

Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L29
a
59Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05747 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05747

Find similar proteins by: Sequence  |  Structure

Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L7-A
b
244Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05737 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05737

Find similar proteins by: Sequence  |  Structure

Entity ID: 28
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L30
c
105Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P14120 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P14120

Find similar proteins by: Sequence  |  Structure

Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L31-A
d
113Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0C2H8 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0C2H8

Find similar proteins by: Sequence  |  Structure

Entity ID: 31
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L33-A
f
107Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05744 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05744

Find similar proteins by: Sequence  |  Structure

Entity ID: 32
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L34-A
g
121Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P87262 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P87262

Find similar proteins by: Sequence  |  Structure

Entity ID: 33
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L36-A
h
100Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P05745 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P05745

Find similar proteins by: Sequence  |  Structure

Entity ID: 34
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L37-A
i
88Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P49166 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P49166

Find similar proteins by: Sequence  |  Structure

Entity ID: 35
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L38
j
78Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P49167 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P49167

Find similar proteins by: Sequence  |  Structure

Entity ID: 36
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L39
k
51Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P04650 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04650

Find similar proteins by: Sequence  |  Structure

Entity ID: 37
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L42-A
l
106Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX27 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX27

Find similar proteins by: Sequence  |  Structure

Entity ID: 38
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L43-A
m
92Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CX25 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CX25

Find similar proteins by: Sequence  |  Structure

Entity ID: 39
MoleculeChainsSequence LengthOrganismDetails
Eukaryotic translation initiation factor 6
n
245Saccharomyces cerevisiaeMutation(s): 0
Find proteins for Q12522 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q12522

Find similar proteins by: Sequence  |  Structure

Entity ID: 40
MoleculeChainsSequence LengthOrganismDetails
Cytoplasmic 60S subunit biogenesis factor REH1
z
432Saccharomyces cerevisiaeMutation(s): 0
Find proteins for Q06709 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  Q06709

Find similar proteins by: Sequence  |  Structure

Entity ID: 41
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal export protein NMD3
w
518Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P38861 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38861

Find similar proteins by: Sequence  |  Structure

Entity ID: 42
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L24-A
v
155Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P04449 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P04449

Find similar proteins by: Sequence  |  Structure

Entity ID: 44
MoleculeChainsSequence LengthOrganismDetails
uL1
p
210Saccharomyces cerevisiaeMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.

Find similar proteins by: Sequence  |  Structure

Entity ID: 45
MoleculeChainsSequence LengthOrganismDetails
Ubiquitin-60S ribosomal protein L40
t
128Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0CH08 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0CH08

Find similar proteins by: Sequence  |  Structure

Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L27-A
Y
136Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P0C2H6 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P0C2H6

Find similar proteins by: Sequence  |  Structure

Entity ID: 30
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L32
e
130Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P38061 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P38061

Find similar proteins by: Sequence  |  Structure

Entity ID: 43
MoleculeChainsSequence LengthOrganismDetails
Large subunit GTPase 1
o
640Saccharomyces cerevisiaeMutation(s): 0
EC: 3.6.1
Find proteins for P53145 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P53145

Find similar proteins by: Sequence  |  Structure

Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
60S ribosomal protein L8-A
H
256Saccharomyces cerevisiaeMutation(s): 0
Find proteins for P17076 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Go to UniProtKB:  P17076

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 1
MoleculeChainsLengthOrganism
25S ribosomal RNAA3396Saccharomyces cerevisiae

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 46
MoleculeChainsLengthOrganism
5S ribosomal RNAx121Saccharomyces cerevisiae

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 47
MoleculeChainsLengthOrganism
5.8S ribosomal RNAy158Saccharomyces cerevisiae
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download CCD File
g, i, l, m, t, w
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
BloodwiseUnited Kingdom12048
Medical Research Council (United Kingdom)United Kingdom105161083

Revision History

  • Version 1.0: 2019-06-26
    Type: Initial release
  • Version 1.1: 2019-07-10
    Changes: Data collection, Database references, Source and taxonomy, Structure summary
