6OL9

Structure of the M5 muscarinic acetylcholine receptor (M5-T4L) bound to tiotropium


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.541 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.236

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Crystal structure of the M5muscarinic acetylcholine receptor.

Vuckovic, Z.Gentry, P.R.Berizzi, A.E.Hirata, K.Varghese, S.Thompson, G.van der Westhuizen, E.T.Burger, W.A.C.Rahmani, R.Valant, C.Langmead, C.J.Lindsley, C.W.Baell, J.B.Tobin, A.B.Sexton, P.M.Christopoulos, A.Thal, D.M.

(2019) Proc.Natl.Acad.Sci.USA 116: 26001-26007

  • DOI: 10.1073/pnas.1914446116

  • PubMed Abstract:
  • The human M <sub>5 </sub> muscarinic acetylcholine receptor (mAChR) has recently emerged as an exciting therapeutic target for treating a range of disorders, including drug addiction. However, a lack of structural information for this receptor subtyp ...

    The human M 5 muscarinic acetylcholine receptor (mAChR) has recently emerged as an exciting therapeutic target for treating a range of disorders, including drug addiction. However, a lack of structural information for this receptor subtype has limited further drug development and validation. Here we report a high-resolution crystal structure of the human M 5 mAChR bound to the clinically used inverse agonist, tiotropium. This structure allowed for a comparison across all 5 mAChR family members that revealed important differences in both orthosteric and allosteric sites that could inform the rational design of selective ligands. These structural studies, together with chimeric swaps between the extracellular regions of the M 2 and M 5 mAChRs, provided structural insight into kinetic selectivity, where ligands show differential residency times between related family members. Collectively, our study provides important insights into the nature of orthosteric and allosteric ligand interaction across the mAChR family that could be exploited for the design of selective drugs.


    Organizational Affiliation

    RIKEN SPring-8 Center, 1-1-1 Kouto, Sayo, Hyogo 679-5148, Japan.,Drug Discovery Biology, Monash Institute of Pharmaceutical Sciences, Monash University, Parkville, VIC 3052, Australia; arthur.christopoulos@monash.edu david.thal@monash.edu.,Drug Discovery Biology, Monash Institute of Pharmaceutical Sciences, Monash University, Parkville, VIC 3052, Australia.,School of Pharmacy, Fudan University, 201203 Shanghai, China.,Centre for Translational Pharmacology, Institute of Molecular, Cell and Systems Biology, College of Medical, Veterinary and Life Sciences, University of Glasgow, G12 8QQ Glasgow, United Kingdom.,Department of Pharmacology, Vanderbilt Center for Neuroscience Drug Discovery, Vanderbilt University, Nashville, TN 37232.,Department of Chemistry, Vanderbilt Center for Neuroscience Drug Discovery, Vanderbilt University, Nashville, TN 37232.,Medicinal Chemistry, Monash Institute of Pharmaceutical Sciences, Monash University, Parkville, VIC 3052, Australia.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Muscarinic acetylcholine receptor M5, T4 Lysozyme fusion
A
480Homo sapiensEnterobacteria phage T4
This entity is chimeric
Mutation(s): 0
Gene Names: CHRM5, e
EC: 3.2.1.17
Membrane protein
mpstruc
Group:
TRANSMEMBRANE PROTEINS: ALPHA-HELICAL
Sub Group:
G Protein-Coupled Receptors (GPCRs)
Protein:
M5 human muscarinic acetylcholine receptor with bound tiotropium
Find proteins for P08912 (Homo sapiens)
Go to Gene View: CHRM5
Go to UniProtKB:  P08912
Find proteins for D9IEF7 (Enterobacteria phage T4)
Go to UniProtKB:  D9IEF7
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
0HK
Query on 0HK

Download SDF File
Download CCD File
A
(1R,2R,4S,5S,7S)-7-{[hydroxy(dithiophen-2-yl)acetyl]oxy}-9,9-dimethyl-3-oxa-9-azoniatricyclo[3.3.1.0~2,4~]nonane
Tiotropium
C19 H22 N O4 S2
LERNTVKEWCAPOY-DZZGSBJMSA-N
 Ligand Interaction
OLC
Query on OLC

Download SDF File
Download CCD File
A
(2R)-2,3-dihydroxypropyl (9Z)-octadec-9-enoate
1-Oleoyl-R-glycerol
C21 H40 O4
RZRNAYUHWVFMIP-GDCKJWNLSA-N
 Ligand Interaction
P33
Query on P33

Download SDF File
Download CCD File
A
3,6,9,12,15,18-HEXAOXAICOSANE-1,20-DIOL
HEPTAETHYLENE GLYCOL, PEG330
C14 H30 O8
XPJRQAIZZQMSCM-UHFFFAOYSA-N
 Ligand Interaction
OLA
Query on OLA

Download SDF File
Download CCD File
A
OLEIC ACID
C18 H34 O2
ZQPPMHVWECSIRJ-KTKRTIGZSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.541 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.236
  • Space Group: C 1 2 1
Unit Cell:
Length (Å)Angle (°)
a = 97.060α = 90.00
b = 63.310β = 102.11
c = 91.620γ = 90.00
Software Package:
Software NamePurpose
PHENIXrefinement
XSCALEdata scaling
PHENIXphasing
XDSdata reduction

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Wellcome TrustUnited Kingdom201529/Z/16/Z
National Health and Medical Research Council (NHMRC, Australia)AustraliaAPP1138448

Revision History

  • Version 1.0: 2019-12-11
    Type: Initial release
  • Version 1.1: 2020-01-01
    Type: Database references
