6LQD

Structure of Enterovirus 71 in complex with NLD-22


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.26 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report



Literature

Design, Synthesis, and Evaluation of Novel Enterovirus 71 Inhibitors as Therapeutic Drug Leads for the Treatment of Human Hand, Foot, and Mouth Disease.

Zhang, M.Wang, Y.He, W.Sun, Y.Guo, Y.Zhong, W.Gao, Q.Liao, M.Wang, X.Cai, Y.Guo, Y.Rao, Z.

(2020) J Med Chem 63: 1233-1244

  • DOI: 10.1021/acs.jmedchem.9b01414
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Human hand, foot, and mouth disease (HFMD) is a serious public health threat with high infection rates in children and infants who reside in Asia and the Pacific regions, and no effective drugs are currently available. Enterovirus 71 (EV71) and coxsa ...

    Human hand, foot, and mouth disease (HFMD) is a serious public health threat with high infection rates in children and infants who reside in Asia and the Pacific regions, and no effective drugs are currently available. Enterovirus 71 (EV71) and coxsackievirus A16 are the major etiological pathogens. Based on an essential hydrophobic pocket on the viral capsid protein VP1, we designed and synthesized a series of small molecular weight compounds as inhibitors of EV71. A potential drug candidate named NLD-22 exhibited excellent antiviral activity (with an EC 50 of 5.056 nM and a 100% protection rate for mice at a dose of 20 mg/kg) and low toxicity. NLD-22 had a favorable pharmacokinetic profile. High-resolution cryo-electron microscopy structural analysis confirmed NLD-22 bound to the hydrophobic pocket in VP1 to block viral infection. In general, NLD-22 was indicated to be a promising potential drug candidate for the treatment of HFMD.


    Organizational Affiliation

    Frontiers Science Center for Cell Responses , Nankai University , Tianjin 300350 , People's Republic of China.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP1
A
297Enterovirus A71Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
Find proteins for B2ZUN0 (Human enterovirus 71)
Go to UniProtKB:  B2ZUN0

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP2
B
254Enterovirus A71Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
Find proteins for B2ZUN0 (Human enterovirus 71)
Go to UniProtKB:  B2ZUN0

Find similar proteins by: Sequence  |  Structure

Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP3
C
242Enterovirus A71Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
Find proteins for B2ZUN0 (Human enterovirus 71)
Go to UniProtKB:  B2ZUN0

Find similar proteins by: Sequence  |  Structure

Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
Capsid protein VP4
D
69Enterovirus A71Mutation(s): 0
EC: 3.4.22.29 (PDB Primary Data), 3.6.1.15 (PDB Primary Data), 3.4.22.28 (PDB Primary Data), 2.7.7.48 (PDB Primary Data)
Find proteins for B2ZUN0 (Human enterovirus 71)
Go to UniProtKB:  B2ZUN0
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
EQ9
Query on EQ9

Download CCD File
A
1-(2-azanylpyridin-4-yl)-3-[5-[4-(5-methyl-1,2,4-oxadiazol-3-yl)phenoxy]pentyl]imidazolidin-2-one
C22 H26 N6 O3
HBOHAJJGWJLRSS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.26 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China2017YFC840300

Revision History

  • Version 1.0: 2020-03-11
    Type: Initial release
