6LKQ

The Structural Basis for Inhibition of Ribosomal Translocation by Viomycin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.210

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

The structural basis for inhibition of ribosomal translocation by viomycin.

Zhang, L.Wang, Y.H.Zhang, X.Lancaster, L.Zhou, J.Noller, H.F.

(2020) Proc Natl Acad Sci U S A 117: 10271-10277

  • DOI: 10.1073/pnas.2002888117
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Viomycin, an antibiotic that has been used to fight tuberculosis infections, is believed to block the translocation step of protein synthesis by inhibiting ribosomal subunit dissociation and trapping the ribosome in an intermediate state of intersubu ...

    Viomycin, an antibiotic that has been used to fight tuberculosis infections, is believed to block the translocation step of protein synthesis by inhibiting ribosomal subunit dissociation and trapping the ribosome in an intermediate state of intersubunit rotation. The mechanism by which viomycin stabilizes this state remains unexplained. To address this, we have determined cryo-EM and X-ray crystal structures of Escherichia coli 70S ribosome complexes trapped in a rotated state by viomycin. The 3.8-Å resolution cryo-EM structure reveals a ribosome trapped in the hybrid state with 8.6° intersubunit rotation and 5.3° rotation of the 30S subunit head domain, bearing a single P/E state transfer RNA (tRNA). We identify five different binding sites for viomycin, four of which have not been previously described. To resolve the details of their binding interactions, we solved the 3.1-Å crystal structure of a viomycin-bound ribosome complex, revealing that all five viomycins bind to ribosomal RNA. One of these (Vio1) corresponds to the single viomycin that was previously identified in a complex with a nonrotated classical-state ribosome. Three of the newly observed binding sites (Vio3, Vio4, and Vio5) are clustered at intersubunit bridges, consistent with the ability of viomycin to inhibit subunit dissociation. We propose that one or more of these same three viomycins induce intersubunit rotation by selectively binding the rotated state of the ribosome at dynamic elements of 16S and 23S rRNA, thus, blocking conformational changes associated with molecular movements that are required for translocation.


    Organizational Affiliation

    Center for Molecular Biology of RNA, University of California, Santa Cruz, CA 95064 jiezh@zju.edu.cn harry@nuvolari.ucsc.edu.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S2
A
218Escherichia coliMutation(s): 0
Gene Names:
rpsBA6581_19565A6592_02990A8C65_17850A9819_00790A9P13_21180A9R57_04400AC067_04635AJ318_03080AM446_22760AM464_17645AM465_25885AML35_22875APT94_19995APU18_02555ARC77_20180AU473_25970AUQ13_07500AW059_09840AWE53_010740AWF59_003780AWG78_007095AWG90_002345AWP75_13480AZZ83_003980B6V57_00930B7C53_01360B9M99_16250B9N33_22515B9T59_07520BANRA_00547BANRA_02273BANRA_03339BE963_14830BEN53_03085BER14_07785BFD68_21815BHF03_16550BHF46_07885BHS87_00800BIQ87_00790BIU72_13410BIZ41_19080BJJ90_21360BK248_07255BK334_15020BK373_09595BK375_04645BK383_20240BMT49_02175BMT91_01365BON65_09430BON66_02955BON75_17145BON83_24855BON86_04410BON87_26695BON91_06960BON92_02750BON96_17215BTQ04_14405BUE81_01710BvCms12BK_00034BvCms2454_04107BvCms35BK_02145BvCmsC61A_04364BvCmsHHP001_04838BvCmsHHP019_00044BvCmsHHP056_04094BvCmsKKP036_03788BvCmsKSNP120_00104BvCmsKSP026_04711BvCmsKSP058_03767BvCmsKSP076_03014BvCmsNSP007_03764BvCmsSINP022_00326BW690_02470BWI89_14055BWP17_11915BXT93_00705BZL31_14940BZL69_20205C2M16_10795C2U48_09610C4K41_20910C4M78_19960C5715_17350C5N07_08575C5P44_18010C6669_04250C6B13_04325C7B06_05860C7B07_04280C7B08_09695C7B18_05305C9E25_15390C9E67_25210C9Z23_08405C9Z29_10375C9Z39_04990C9Z43_09525C9Z68_04785C9Z70_08115C9Z78_00165C9Z78_02775CA593_02870CCZ14_20505CCZ17_20470CDC27_24690CDL37_07245CG692_09500CI693_15090CI694_28160CIG45_06990CQP61_22090CR539_04935CRE06_00170CRT43_00990CRX46_05020CSB64_09595CT146_12115CUB99_08015CVH05_24475CWM24_05035D0X26_09420D1912_13690D2185_20130D2188_12785D3821_06210D3822_17335D3O91_03185D3P01_06970D3Y67_16405D4M06_01450D4V08_16070D6T60_04050D6X76_09800D7K63_00165D7K66_11610D7Y10_00165D9D20_18630D9D31_08885D9D33_03385D9D43_02305D9E34_01105D9E35_14530D9E49_02145D9F17_00165D9G11_19100D9G42_07585D9G48_08785D9H36_21790D9H53_14245D9H68_13775D9H70_04355D9I20_08115D9I37_13510D9I87_01640D9I88_06435D9I97_03805D9J03_00165D9J11_16825D9J60_02075D9J78_12380D9K54_16750D9L89_00165D9L99_05940D9X97_00165DAH26_11215DAH34_04190DAH37_16335DAH43_04025DBQ99_21360DD762_01090DEN86_04070DJ487_06020DJ492_12760DJ503_00895DL455_01615DLW88_03755DM102_18365DM129_14540DMI04_00170DMZ50_04115DN627_10245DNB37_01435DND16_04815DNR41_13200DNX30_02270DOY56_00170DP258_09355DQE83_10255DS966_12905DTL43_05925DTL90_09735DTM10_02780DTM45_12630DU309_06140DU321_03650DU333_05950DW236_10615DWB25_20305DXT73_18920DXX80_017135E0L04_16465E0L12_05055E2112_01240E2115_17375E2116_17400E2119_15580E2127_15010E2128_01350E2129_02860E2134_11975E2135_11635E2148_14070E4K55_06965E5P22_04090E5P28_13975E5P37_21190E5S46_19535E5S58_05605E5S61_20145EA250_20395EA410_04885EA834_19145EAI42_08300EAI52_11005EB509_04560EB510_04565EB515_00165EC3234A_2c01500EC3426_00920EC382_02955ECONIH1_00890ECs0171ECTO124_04042ECTO6_03894ED225_10455ED607_02625ED611_09635ED648_00165ED903_08485ED944_00165EEA45_04510EEP23_00165EF173_00165EGT48_20250EI021_19845EI028_17525EI032_14690EIA08_06325EIA21_00165EIZ93_07925EL75_3596EL79_3705EL80_3652ELT20_04470ELT23_12175ELT33_15870ELT34_19890ELT48_12180ELT49_18475ELT58_11815ELU82_16775ELU85_21270ELU96_20275ELV05_06475ELV13_13145ELV15_10275ELV24_19200ELV28_04185ELX79_12490ELX83_20605ELY23_06765ELY24_11290ELY50_16140EO241_11800EPS76_09885EPS91_15145EPS94_12740EPT01_02595EPU41_00950EQ820_08895EQ823_16635EQ825_22910EQ830_01905ERL57_05895ERS085365_03087ERS085366_02719ERS085383_01177ERS085386_01543ERS085404_00708ERS085406_00569ERS085411_00031ERS085416_03650ERS139211_02987ERS150873_01111EST51_20100EVY14_15615EWK56_14885EXM29_15760ExPECSC019_03545ExPECSC038_03990ExPECSC065_04179EXX06_08815EXX13_05315EXX23_14665EXX53_06965EXX55_08280EXX71_19560EXX87_03335EYD11_18540EYX82_24365EYX99_20960EYY27_25445EYY34_22885F7F11_02075F7G01_02645F7G03_01455FAF34_018075FKO60_12340FNJ67_21465FNJ69_22375FNJ83_02345FORC82_3871FQU83_21885FRV13_02390FV293_02895FV295_13970FV438_03735FY127_02945GJ11_00885HmCms184_03911HmCmsJML074_03001HmCmsJML146_01754HmCmsJML204_00825HMPREF3040_02610MJ49_06195MS6198_01840MS8345_00167NCTC10082_01383NCTC10089_04076NCTC10090_02160NCTC10767_03962NCTC10974_04616NCTC11126_03634NCTC12950_04424NCTC13127_05455NCTC13148_05196NCTC13846_03878NCTC7922_05813NCTC7927_04507NCTC7928_04613NCTC8450_01117NCTC8500_04546NCTC8621_04202NCTC8959_04843NCTC9007_00459NCTC9044_03184NCTC9045_04711NCTC9050_02026NCTC9058_02797NCTC9062_04214NCTC9117_05053NCTC9119_04267NCTC9434_02610NCTC9701_04378NCTC9702_04760NCTC9706_01337NCTC9777_00472NCTC9969_04265PGD_03810RK56_028000SAMEA3472044_04157SAMEA3472047_02498SAMEA3472056_00973SAMEA3472080_03752SAMEA3472090_04487SAMEA3472108_03201SAMEA3472110_04513SAMEA3472112_04653SAMEA3472147_00380SAMEA3484427_01375SAMEA3484429_01106SAMEA3484434_01147SAMEA3485113_00840SAMEA3752372_04458SAMEA3752557_00874SAMEA3752559_03712SAMEA3752620_02090SAMEA3753097_03905SAMEA3753164_02433SAMEA3753300_01863SK85_00168SY51_00965U12A_00178U14A_00177UC41_07420UN91_10580WQ89_09555YDC107_3394

Find proteins for C3TPN2 (Escherichia coli)
Go to UniProtKB:  C3TPN2

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S3
B
206Escherichia coliMutation(s): 0
Gene Names: rpsCNCTC9094_00425
Find proteins for A0A376HTV6 (Escherichia coli)
Go to UniProtKB:  A0A376HTV6

Find similar proteins by: Sequence  |  Structure

Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S4
C
205Escherichia coliMutation(s): 0
Find proteins for A0A4P8BV83 (Escherichia coli O145:NM)
Go to UniProtKB:  A0A4P8BV83

Find similar proteins by: Sequence  |  Structure

Entity ID: 4
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S5
D
150Escherichia coliMutation(s): 0
Find proteins for F4SQ30 (Escherichia coli H736)
Go to UniProtKB:  F4SQ30

Find similar proteins by: Sequence  |  Structure

Entity ID: 5
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S6
E
100Escherichia coliMutation(s): 0
Gene Names: rpsFD9J60_11985
Find proteins for A0A3L2GT12 (Escherichia coli)
Go to UniProtKB:  A0A3L2GT12

Find similar proteins by: Sequence  |  Structure

Entity ID: 6
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S7
F
151Escherichia coliMutation(s): 0
Find proteins for D6I218 (Escherichia coli B088)
Go to UniProtKB:  D6I218

Find similar proteins by: Sequence  |  Structure

Entity ID: 7
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S8
G
129Escherichia coliMutation(s): 0
Find proteins for U9ZUM7 (Escherichia coli 907713)
Go to UniProtKB:  U9ZUM7

Find similar proteins by: Sequence  |  Structure

Entity ID: 8
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S9
H
127Escherichia coliMutation(s): 0
Find proteins for D8A919 (Escherichia coli (strain MS 21-1))
Go to UniProtKB:  D8A919

Find similar proteins by: Sequence  |  Structure

Entity ID: 9
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S10
I
98Escherichia coliMutation(s): 0
Gene Names: rpsJFTV90_00850
Find proteins for A0A5B9AU26 (Escherichia coli)
Go to UniProtKB:  A0A5B9AU26

Find similar proteins by: Sequence  |  Structure

Entity ID: 10
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S11
J
117Escherichia coliMutation(s): 0
Find proteins for A0A4P8B3R1 (Escherichia coli O157:H7)
Go to UniProtKB:  A0A4P8B3R1

Find similar proteins by: Sequence  |  Structure

Entity ID: 11
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S12
K
123Escherichia coliMutation(s): 0
Find proteins for L3C3P4 (Escherichia coli KTE193)
Go to UniProtKB:  L3C3P4

Find similar proteins by: Sequence  |  Structure

Entity ID: 12
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S13
L
114Escherichia coliMutation(s): 0
Find proteins for A0A069XLE9 (Escherichia coli 3-373-03_S4_C2)
Go to UniProtKB:  A0A069XLE9

Find similar proteins by: Sequence  |  Structure

Entity ID: 13
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S14
M
100Escherichia coliMutation(s): 0
Gene Names: rpsNBvCmsNSP072_04005D9J44_12955ERS085374_04715SAMEA3485113_04711
Find proteins for A0A090BZT4 (Escherichia coli)
Go to UniProtKB:  A0A090BZT4

Find similar proteins by: Sequence  |  Structure

Entity ID: 14
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S15
N
88Escherichia coliMutation(s): 0
Find proteins for A0A029IK47 (Escherichia coli 2-005-03_S4_C2)
Go to UniProtKB:  A0A029IK47

Find similar proteins by: Sequence  |  Structure

Entity ID: 15
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S16
O
82Escherichia coliMutation(s): 0
Find proteins for A0A029IMB2 (Escherichia coli 2-005-03_S4_C2)
Go to UniProtKB:  A0A029IMB2

Find similar proteins by: Sequence  |  Structure

Entity ID: 16
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S17
P
80Escherichia coliMutation(s): 0
Find proteins for T6LV72 (Escherichia coli HVH 87)
Go to UniProtKB:  T6LV72

Find similar proteins by: Sequence  |  Structure

Entity ID: 17
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S18
Q
55Escherichia coliMutation(s): 0
Find proteins for E9TDX6 (Escherichia coli MS 117-3)
Go to UniProtKB:  E9TDX6

Find similar proteins by: Sequence  |  Structure

Entity ID: 18
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S19
R
79Escherichia coliMutation(s): 0
Find proteins for S1EA57 (Escherichia coli KTE73)
Go to UniProtKB:  S1EA57

Find similar proteins by: Sequence  |  Structure

Entity ID: 19
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S20
S
85Escherichia coliMutation(s): 0
Find proteins for D7ZAS2 (Escherichia coli MS 69-1)
Go to UniProtKB:  D7ZAS2

Find similar proteins by: Sequence  |  Structure

Entity ID: 20
MoleculeChainsSequence LengthOrganismDetails
30S ribosomal protein S21
T
51Escherichia coliMutation(s): 0
Gene Names: rpsUFWK02_18995
Find proteins for A0A5C9AJ78 (Escherichia coli)
Go to UniProtKB:  A0A5C9AJ78

Find similar proteins by: Sequence  |  Structure

Entity ID: 21
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L2
U
271Escherichia coliMutation(s): 0
Find proteins for A0A1X3LPI5 (Escherichia coli TA249)
Go to UniProtKB:  A0A1X3LPI5

Find similar proteins by: Sequence  |  Structure

Entity ID: 22
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L3
V
209Escherichia coliMutation(s): 0
Find proteins for I2X6U5 (Escherichia coli 2.3916)
Go to UniProtKB:  I2X6U5

Find similar proteins by: Sequence  |  Structure

Entity ID: 23
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L4
W
201Escherichia coliMutation(s): 0
Find proteins for L3C159 (Escherichia coli KTE193)
Go to UniProtKB:  L3C159

Find similar proteins by: Sequence  |  Structure

Entity ID: 24
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L5
X
177Escherichia coliMutation(s): 0
Find proteins for H4IXW7 (Escherichia coli DEC1C)
Go to UniProtKB:  H4IXW7

Find similar proteins by: Sequence  |  Structure

Entity ID: 25
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L6
Y
176Escherichia coliMutation(s): 0
Find proteins for V0AIU3 (Escherichia coli 909945-2)
Go to UniProtKB:  V0AIU3

Find similar proteins by: Sequence  |  Structure

Entity ID: 26
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L11
Z
141Escherichia coliMutation(s): 0
Find proteins for H4J053 (Escherichia coli DEC1C)
Go to UniProtKB:  H4J053

Find similar proteins by: Sequence  |  Structure

Entity ID: 27
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L13
0
142Escherichia coliMutation(s): 0
Find proteins for S1EW51 (Escherichia coli KTE73)
Go to UniProtKB:  S1EW51

Find similar proteins by: Sequence  |  Structure

Entity ID: 28
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L14
1
122Escherichia coliMutation(s): 0
Find proteins for V0YSM1 (Escherichia coli 908573)
Go to UniProtKB:  V0YSM1

Find similar proteins by: Sequence  |  Structure

Entity ID: 29
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L15
2
143Escherichia coliMutation(s): 0
Gene Names:
Find proteins for A0A037Y8L6 (Escherichia coli)
Go to UniProtKB:  A0A037Y8L6

Find similar proteins by: Sequence  |  Structure

Entity ID: 30
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L16
3
136Escherichia coliMutation(s): 0
Find proteins for H4LI23 (Escherichia coli DEC2E)
Go to UniProtKB:  H4LI23

Find similar proteins by: Sequence  |  Structure

Entity ID: 31
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L17
4
120Escherichia coliMutation(s): 0
Find proteins for A0A1X3LC97 (Escherichia coli TA054)
Go to UniProtKB:  A0A1X3LC97

Find similar proteins by: Sequence  |  Structure

Entity ID: 32
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L18
5
116Escherichia coliMutation(s): 0
Find proteins for H4JDL8 (Escherichia coli DEC1D)
Go to UniProtKB:  H4JDL8

Find similar proteins by: Sequence  |  Structure

Entity ID: 33
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L19
6
114Escherichia coliMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.

Find similar proteins by: Sequence  |  Structure

Entity ID: 34
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L20
8
117Escherichia coliMutation(s): 0
Find proteins for V6FS92 (Escherichia coli 99.0741)
Go to UniProtKB:  V6FS92

Find similar proteins by: Sequence  |  Structure

Entity ID: 35
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L21
9
103Escherichia coliMutation(s): 0
Find proteins for L4V445 (Escherichia coli KTE112)
Go to UniProtKB:  L4V445

Find similar proteins by: Sequence  |  Structure

Entity ID: 36
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L22
a
110Escherichia coliMutation(s): 0
Find proteins for F4TL38 (Escherichia coli M718)
Go to UniProtKB:  F4TL38

Find similar proteins by: Sequence  |  Structure

Entity ID: 37
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L23
b
93Escherichia coliMutation(s): 0
Find proteins for S1EUY1 (Escherichia coli KTE73)
Go to UniProtKB:  S1EUY1

Find similar proteins by: Sequence  |  Structure

Entity ID: 38
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L24
c
102Escherichia coliMutation(s): 0
Find proteins for F4TL32 (Escherichia coli M718)
Go to UniProtKB:  F4TL32

Find similar proteins by: Sequence  |  Structure

Entity ID: 39
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L25
d
94Escherichia coliMutation(s): 0
Find proteins for D7Y4U5 (Escherichia coli MS 115-1)
Go to UniProtKB:  D7Y4U5

Find similar proteins by: Sequence  |  Structure

Entity ID: 40
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L27
e
79Escherichia coliMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.

Find similar proteins by: Sequence  |  Structure

Entity ID: 41
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L28
f
77Escherichia coliMutation(s): 0
Find proteins for A0A5B7P765 (Escherichia coli O26:H11)
Go to UniProtKB:  A0A5B7P765

Find similar proteins by: Sequence  |  Structure

Entity ID: 42
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L29
g
63Escherichia coliMutation(s): 0
Find proteins for I2X6R6 (Escherichia coli 2.3916)
Go to UniProtKB:  I2X6R6

Find similar proteins by: Sequence  |  Structure

Entity ID: 43
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L30
h
58Escherichia coliMutation(s): 0
Find proteins for A0A073FR56 (Escherichia coli 2-427-07_S4_C3)
Go to UniProtKB:  A0A073FR56

Find similar proteins by: Sequence  |  Structure

Entity ID: 44
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L32
i
56Escherichia coliMutation(s): 0
Find proteins for D7XI28 (Escherichia coli MS 84-1)
Go to UniProtKB:  D7XI28

Find similar proteins by: Sequence  |  Structure

Entity ID: 45
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L33
j
50Escherichia coliMutation(s): 0
Find proteins for L3NSS9 (Escherichia coli KTE66)
Go to UniProtKB:  L3NSS9

Find similar proteins by: Sequence  |  Structure

Entity ID: 46
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L34
k
46Escherichia coliMutation(s): 0
Find proteins for A0A1X3IEM2 (Escherichia coli E1114)
Go to UniProtKB:  A0A1X3IEM2

Find similar proteins by: Sequence  |  Structure

Entity ID: 47
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L35
l
64Escherichia coliMutation(s): 0
Find proteins for L3P377 (Escherichia coli KTE66)
Go to UniProtKB:  L3P377

Find similar proteins by: Sequence  |  Structure

Entity ID: 48
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L36
m
38Escherichia coliMutation(s): 0
Find proteins for F4V714 (Escherichia coli TA280)
Go to UniProtKB:  F4V714

Find similar proteins by: Sequence  |  Structure

Entity ID: 49
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L10
n
163Escherichia coliMutation(s): 0
Find proteins for A0A1X3LA41 (Escherichia coli TA054)
Go to UniProtKB:  A0A1X3LA41

Find similar proteins by: Sequence  |  Structure

Entity ID: 50
MoleculeChainsSequence LengthOrganismDetails
50S ribosomal protein L7/L12
o, p, q, r
30Escherichia coliMutation(s): 0
Gene Names: rplLBvCmsKKP036_03582CQB02_21450
Find proteins for A0A4C9D1M4 (Escherichia coli)
Go to UniProtKB:  A0A4C9D1M4

Find similar proteins by: Sequence  |  Structure

Entity ID: 54
MoleculeChainsSequence LengthOrganismDetails
Peptide chain release factor 3
v
525Escherichia coliMutation(s): 0
Gene Names:
prfCA6592_04090A9819_24895A9P13_22280AM446_23880APT94_26745APU18_05660ARC77_19140AU473_27010AW059_08770AWE53_009720AWF59_004815AWG78_008420AWG90_001320B6V57_25825B7C53_16745B9M99_13090B9T59_08605BE963_13730BEN53_02000BIQ87_25000BK292_12635BK296_03565BK334_23560BK375_05695BK383_08010BON66_13380BON69_06980BON83_25940BON86_14100BON87_19305BON91_08050BTQ04_23865BvCms35BK_02339BvCmsC61A_04169BvCmsKSP076_01357BvCmsSINP022_00133BWP17_03290BZL69_04535C4M78_04330C6B13_05410C7B06_04825C7B07_05320C7B08_12205C9E25_18240C9Z29_11365C9Z70_09130C9Z78_01140C9Z78_01800CDC27_23620CO706_22040CQP61_23130CRE06_01225CRM83_16110CRX46_08470CSB64_20240CVH05_08650D3P01_08040D4M06_02510D4V08_15195D6X76_13610D7K63_01185D7K66_00530D9D31_02535D9D33_04435D9E34_05080D9E49_03180D9F17_01140D9G11_20135D9G42_08575D9H36_11075D9I20_09105D9J03_08845D9J46_24105D9J78_18550D9K54_15750D9L89_01175D9X97_01175DAH43_02965DJ487_07090DJ492_15720DM102_03510DM129_14235DMI04_01235DN627_19210DNB37_02495DND16_26005DNX30_03355DOY56_01235DP258_19205DS966_19590DTL90_19440DTM10_01760DU321_02625DW236_09545DWB25_21390DXX80_016145E0L12_12060E2115_07710E2116_05915E5S46_05040E5S58_22630E5S61_04945EA250_12685EA410_05935EAI52_14785EB509_11720EB510_06525EB515_01160ECs5333ED225_13205ED607_14660ED611_13460ED903_11920ED944_01160EEA45_16055EF173_01160ELT33_16890ELT58_08165ELU85_12220ELV05_08500ELV15_04515ELV28_15045EPU41_24455EQ820_17955EQ823_02985EQ830_02930EXM29_16750ExPECSC019_03346ExPECSC038_04189EXX13_04315EXX23_13025EXX53_09860EYX82_09370EYY27_03920F7F11_03075F7G01_01655F7G03_00465FKO60_13500FNJ69_21335FNJ83_01320FV295_13040HmCmsJML074_02111HmCmsJML146_04652HmCmsJML204_00635MJ49_07195MS6198_51560NCTC9058_02594NCTC9434_02405NCTC9701_04578PGD_03617SAMEA3472090_00813SAMEA3484434_03165SAMEA3485101_00902SAMEA3752620_01894SAMEA3753164_02629UC41_15680UN86_17350

Find proteins for C3SE77 (Escherichia coli)
Go to UniProtKB:  C3SE77
  • Find similar proteins by: Sequence   |   Structure
Entity ID: 56
MoleculeChainsSequence LengthOrganismDetails
Viomycin
7, AA, BA, y, z
6synthetic constructMutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 51
MoleculeChainsLengthOrganism
16S ribosomal RNAs1532Escherichia coli

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 52
MoleculeChainsLengthOrganism
23S ribosomal RNAt2903Escherichia coli

Find similar nucleic acids by: Sequence   |  Structure

Entity ID: 53
MoleculeChainsLengthOrganism
5S ribosomal RNAu118Escherichia coli
  • Find similar nucleic acids by: Sequence   |   Structure
Entity ID: 55
MoleculeChainsLengthOrganism
messenger RNAw6Escherichia coli
Small Molecules
Biologically Interesting Molecules 1 Unique
IDChainsNameType/Class2D Diagram3D Interactions
PRD_000226
Query on PRD_000226
7, AA, BA, y, zViomycinOligopeptide /  Antibiotic

--

Modified Residues  3 Unique
IDChainsTypeFormula2D DiagramParent
5OH
Query on 5OH
7,AA,BA,y,z
L-PEPTIDE LINKINGC6 H12 N4 O3ALA
DPP
Query on DPP
7,AA,BA,y,z
L-PEPTIDE LINKINGC3 H8 N2 O2ALA
KBE
Query on KBE
7,AA,BA,y,z
L-PEPTIDE LINKINGC6 H14 N2 O2LYS
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.10 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.210
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 257.6α = 90
b = 312.9β = 90
c = 328.6γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China31971226

Revision History

  • Version 1.0: 2020-05-06
    Type: Initial release
  • Version 1.1: 2020-05-13
    Changes: Source and taxonomy, Structure summary
  • Version 1.2: 2020-05-27
    Changes: Database references
