6J2G

Crystal structure of bat (Pteropus Alecto) MHC class I Ptal-N*01:01 in complex with Ebola virus-derived peptide EBOV-NP2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.41 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.197
  • R-Value Observed: 0.199

wwPDB Validation 3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Peptide presentation by bat MHC class I provides new insight into the antiviral immunity of bats.

Lu, D.Liu, K.Zhang, D.Yue, C.Lu, Q.Cheng, H.Wang, L.Chai, Y.Qi, J.Wang, L.F.Gao, G.F.Liu, W.J.

(2019) PLoS Biol 17: e3000436-e3000436

  • DOI: 10.1371/journal.pbio.3000436
  • Structures With Same Primary Citation

  • PubMed Abstract:
  • Bats harbor many zoonotic viruses, including highly pathogenic viruses of humans and other mammals, but they are typically asymptomatic in bats. To further understand the antiviral immunity of bats, we screened and identified a series of bat major hi ...

    Bats harbor many zoonotic viruses, including highly pathogenic viruses of humans and other mammals, but they are typically asymptomatic in bats. To further understand the antiviral immunity of bats, we screened and identified a series of bat major histocompatibility complex (MHC) I Ptal-N*01:01-binding peptides derived from four different bat-borne viruses, i.e., Hendra virus (HeV), Ebola virus (EBOV), Middle East respiratory syndrome coronavirus (MERS-CoV), and H17N10 influenza-like virus. The structures of Ptal-N*01:01 display unusual peptide presentation features in that the bat-specific 3-amino acid (aa) insertion enables the tight "surface anchoring" of the P1-Asp in pocket A of bat MHC I. As the classical primary anchoring positions, the B and F pockets of Ptal-N*01:01 also show unconventional conformations, which contribute to unusual peptide motifs and distinct peptide presentation. Notably, the features of bat MHC I may be shared by MHC I from various marsupials. Our study sheds light on bat adaptive immunity and may benefit future vaccine development against bat-borne viruses of high impact on humans.


    Organizational Affiliation

    NHC Key Laboratory of Medical Virology and Viral Diseases, National Institute for Viral Disease Control and Prevention, Chinese Center for Disease Control and Prevention, Beijing, China.



Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Ptal-N*01:01
A, D
277Pteropus alectoMutation(s): 0
Gene Names: Ptal-N
Find proteins for A0A125R585 (Pteropus alecto)
Go to UniProtKB:  A0A125R585

Find similar proteins by: Sequence  |  Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetails
Beta-2-microglobulin
B, E
99Homo sapiensMutation(s): 0
Gene Names: B2MCDABP0092HDCMA22P
Find proteins for P61769 (Homo sapiens)
Go to UniProtKB:  P61769
NIH Common Fund Data Resources
PHAROS  P61769
  • Find similar proteins by: Sequence   |   Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetails
EBOV-NP2
C, F
11Ebola virus sp.Mutation(s): 0
Protein Feature View is not available: No corresponding UniProt sequence found.
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.41 Å
  • R-Value Free: 0.233
  • R-Value Work: 0.197
  • R-Value Observed: 0.199
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 101.397α = 90
b = 103.307β = 90
c = 180.057γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History

  • Version 1.0: 2019-09-18
    Type: Initial release
  • Version 1.1: 2019-09-25
    Changes: Data collection, Structure summary
  • Version 1.2: 2019-12-04
    Changes: Structure summary
