6IOL

Cryo-EM structure of multidrug efflux pump MexAB-OprM (60 degree state)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.76 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Structures of the wild-type MexAB-OprM tripartite pump reveal its complex formation and drug efflux mechanism.

Tsutsumi, K.Yonehara, R.Ishizaka-Ikeda, E.Miyazaki, N.Maeda, S.Iwasaki, K.Nakagawa, A.Yamashita, E.

(2019) Nat Commun 10: 1520-1520

  • DOI: https://doi.org/10.1038/s41467-019-09463-9
  • Primary Citation of Related Structures:
    6IOK, 6IOL

  • PubMed Abstract:

    In Pseudomonas aeruginosa, MexAB-OprM plays a central role in multidrug resistance by ejecting various drug compounds, which is one of the causes of serious nosocomial infections. Although the structures of the components of MexAB-OprM have been solved individually by X-ray crystallography, no structural information for fully assembled pumps from P. aeruginosa were previously available. In this study, we present the structure of wild-type MexAB-OprM in the presence or absence of drugs at near-atomic resolution. The structure reveals that OprM does not interact with MexB directly, and that it opens its periplasmic gate by forming a complex. Furthermore, we confirm the residues essential for complex formation and observed a movement of the drug entrance gate. Based on these results, we propose mechanisms for complex formation and drug efflux.


  • Organizational Affiliation

    Institute for Protein Research, Osaka University, Suita, 565-0871, Osaka, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Multidrug resistance protein MexA362Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: mexA
Membrane Entity: Yes
UniProt
Find proteins for P52477 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore P52477
Go to UniProtKB:  P52477
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP52477
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Outer membrane protein OprMG [auth A],
H [auth B],
I [auth C]
474Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: oprM
Membrane Entity: Yes
UniProt
Find proteins for Q51487 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore Q51487
Go to UniProtKB:  Q51487
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ51487
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Multidrug resistance protein MexBJ [auth F],
K [auth G],
L [auth E]
1,054Pseudomonas aeruginosa PAO1Mutation(s): 0
Gene Names: mexB
Membrane Entity: Yes
UniProt
Find proteins for P52002 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1))
Explore P52002
Go to UniProtKB:  P52002
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP52002
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.76 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of ScienceJapanJP25291014
Ministry of Education, Culture, Sports, Science and Technology (Japan)JapanJP22121006
Japan Agency for Medical Research and Development (AMED)Japan--

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-03
    Type: Initial release
  • Version 1.1: 2019-04-17
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-27
    Changes: Data collection, Database references
