6GY5

Crystal structure of the kelch domain of human KLHL20 in complex with DAPK1 peptide

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.09 Å
  • R-Value Free: 0.172
  • R-Value Work: 0.153
  • R-Value Observed: 0.154

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history.


Literature

Structural Basis for Recruitment of DAPK1 to the KLHL20 E3 Ligase.

Chen, Z., Picaud, S., Filippakopoulos, P., D'Angiolella, V., Bullock, A.N.

(2019) Structure 27: 1395-1404.e4

  • DOI: 10.1016/j.str.2019.06.005
  • Primary Citation of Related Structures:
    6GY5

  • PubMed Abstract:

    • BTB-Kelch proteins form the largest subfamily of Cullin-RING E3 ligases, yet their substrate complexes are mapped and structurally characterized only for KEAP1 and KLHL3. KLHL20 is a related CUL3-dependent ubiquitin ligase linked to autophagy, cancer, and Alzheimer's disease that promotes the ubiquitination and degradation of substrates including DAPK1, PML, and ULK1 ...

    BTB-Kelch proteins form the largest subfamily of Cullin-RING E3 ligases, yet their substrate complexes are mapped and structurally characterized only for KEAP1 and KLHL3. KLHL20 is a related CUL3-dependent ubiquitin ligase linked to autophagy, cancer, and Alzheimer's disease that promotes the ubiquitination and degradation of substrates including DAPK1, PML, and ULK1. We identified an "LPDLV"-containing motif in the DAPK1 death domain that determines its recruitment and degradation by KLHL20. A 1.1-Å crystal structure of a KLHL20 Kelch domain-DAPK1 peptide complex reveals DAPK1 binding as a loose helical turn that inserts deeply into the central pocket of the Kelch domain to contact all six blades of the β propeller. Here, KLHL20 forms salt-bridge and hydrophobic interactions including tryptophan and cysteine residues ideally positioned for covalent inhibitor development. The structure highlights the diverse binding modes of β-propeller domains versus linear grooves and suggests a new target for structure-based drug design.

    Organizational Affiliation:

    Structural Genomics Consortium, University of Oxford, Old Road Campus, Roosevelt Drive, Oxford OX3 7DQ, UK. Electronic address: alex.bullock@sgc.ox.ac.uk.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Kelch-like protein 20A304Homo sapiensMutation(s): 0
Gene Names: KLHL20, KLEIP, KLHLX
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y2M5 (Homo sapiens)
Explore Q9Y2M5
Go to UniProtKB:  Q9Y2M5
PHAROS:  Q9Y2M5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y2M5
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Death-associated protein kinase 1B [auth U]11Homo sapiensMutation(s): 0
Gene Names: DAPK1, DAPK
EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for P53355 (Homo sapiens)
Explore P53355
Go to UniProtKB:  P53355
PHAROS:  P53355
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53355
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
EDO
Query on EDO
Download Ideal Coordinates CCD File
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N		 Ligand Interaction
CL
Query on CL
Download Ideal Coordinates CCD File
C [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M		 Ligand Interaction
NA
Query on NA
Download Ideal Coordinates CCD File
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
R [auth A],
S [auth A],
T [auth A],
U [auth A],
V [auth A],
W [auth A],
X [auth A],
Y [auth A],
Z [auth A]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.09 Å
  • R-Value Free: 0.172
  • R-Value Work: 0.153
  • R-Value Observed: 0.154
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 40.459α = 90
b = 47.361β = 90
c = 151.933γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Wellcome TrustUnited KingdomH9R00050

Revision History  (Full details and data files)

  • Version 1.0: 2018-08-08
    Type: Initial release
  • Version 1.1: 2019-08-21
    Changes: Data collection, Database references
  • Version 1.2: 2019-09-18
    Changes: Data collection, Database references
