6G86

Structure of Cdc14 bound to SIC1 PxL motif


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.74 Å
  • R-Value Free: 0.199
  • R-Value Work: 0.166
  • R-Value Observed: 0.167

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A PxL motif promotes timely cell cycle substrate dephosphorylation by the Cdc14 phosphatase.

Kataria, M.Mouilleron, S.Seo, M.H.Corbi-Verge, C.Kim, P.M.Uhlmann, F.

(2018) Nat Struct Mol Biol 25: 1093-1102

  • DOI: 10.1038/s41594-018-0152-3
  • Primary Citation of Related Structures:
    6G84, 6G85, 6G86

  • PubMed Abstract:
  • The cell division cycle consists of a series of temporally ordered events. Cell cycle kinases and phosphatases provide key regulatory input, but how the correct substrate phosphorylation and dephosphorylation timing is achieved is incompletely understood ...

    The cell division cycle consists of a series of temporally ordered events. Cell cycle kinases and phosphatases provide key regulatory input, but how the correct substrate phosphorylation and dephosphorylation timing is achieved is incompletely understood. Here we identify a PxL substrate recognition motif that instructs dephosphorylation by the budding yeast Cdc14 phosphatase during mitotic exit. The PxL motif was prevalent in Cdc14-binding peptides enriched in a phage display screen of native disordered protein regions. PxL motif removal from the Cdc14 substrate Cbk1 delays its dephosphorylation, whereas addition of the motif advances dephosphorylation of otherwise late Cdc14 substrates. Crystal structures of Cdc14 bound to three PxL motif substrate peptides provide a molecular explanation for PxL motif recognition on the phosphatase surface. Our results illustrate the sophistication of phosphatase-substrate interactions and identify them as an important determinant of ordered cell cycle progression.


    Organizational Affiliation

    Chromosome Segregation Laboratory, The Francis Crick Institute, London, UK. frank.uhlmann@crick.ac.uk.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tyrosine-protein phosphatase CDC14A, B374Saccharomyces cerevisiaeMutation(s): 0
Gene Names: CDC14OAF3YFR028C
EC: 3.1.3.48
UniProt
Find proteins for Q00684 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q00684
Go to UniProtKB:  Q00684
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ00684
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Protein SIC1D [auth C],
C [auth D]
16Saccharomyces cerevisiaeMutation(s): 0
UniProt
Find proteins for P38634 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38634
Go to UniProtKB:  P38634
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38634
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
P6G
Query on P6G

Download Ideal Coordinates CCD File
F [auth A],
M [auth B],
N [auth B]
HEXAETHYLENE GLYCOL
C12 H26 O7
IIRDTKBZINWQAW-UHFFFAOYSA-N
 Ligand Interaction
MES
Query on MES

Download Ideal Coordinates CCD File
E [auth A],
L [auth B]
2-(N-MORPHOLINO)-ETHANESULFONIC ACID
C6 H13 N O4 S
SXGZJKUKBWWHRA-UHFFFAOYSA-N
 Ligand Interaction
PEG
Query on PEG

Download Ideal Coordinates CCD File
G [auth A],
H [auth A],
I [auth A],
J [auth A],
O [auth B]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
 Ligand Interaction
ZN
Query on ZN

Download Ideal Coordinates CCD File
K [auth A],
P [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.74 Å
  • R-Value Free: 0.199
  • R-Value Work: 0.166
  • R-Value Observed: 0.167
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.09α = 90
b = 94.321β = 90
c = 127.656γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
xia2data reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-17
    Type: Initial release
  • Version 1.1: 2018-11-28
    Changes: Data collection, Database references, Structure summary
  • Version 1.2: 2018-12-19
    Changes: Data collection, Database references
