6CZL | pdb_00006czl

Crystal structure of Medicago truncatula ATP-phosphoribosyltransferase in relaxed form


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.92 Å
  • R-Value Free:
    0.250 (Depositor), 0.244 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.198 (DCC)
  • R-Value Observed:
    0.198 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6CZL

This is version 1.2 of the entry. See complete history

Literature

Guarding the gateway to histidine biosynthesis in plants:Medicago truncatulaATP-phosphoribosyltransferase in relaxed and tense states.

Ruszkowski, M.

(2018) Biochem J 475: 2681-2697

  • DOI: https://doi.org/10.1042/BCJ20180289
  • Primary Citation Related Structures:
    6CZL, 6CZM

  • PubMed Abstract:

    In the first committed step of histidine biosynthesis, adenosine 5'-triphosphate (ATP) and 5-phosphoribosyl-α1-pyrophosphate (PRPP), in the presence of ATP phosphoribosyltransferase (ATP-PRT, EC 2.4.2.17), yield phosphoribosyl-ATP. ATP-PRTs are subject to feedback inhibition by histidine that allosterically binds between the regulatory domains. Histidine biosynthetic pathways of bacteria, lower eukaryotes, and plants are considered promising targets for the design of antibiotics, antifungal agents, and herbicides because higher organisms are histidine heterotrophs. Plant ATP-PRTs are similar to one of the two types of their bacterial counterparts, the long-type ATP-PRTs. A biochemical and structural study of ATP-PRT from the model legume plant, Medicago truncatula ( Medtr ATP-PRT1) is reported herein. Two crystal structures, presenting homohexameric Medtr ATP-PRT1 in its relaxed (R-) and histidine-bound, tense (T-) states allowed to observe key features of the enzyme and provided the first structural insights into an ATP-PRT from a eukaryotic organism. In particular, they show pronounced conformational reorganizations during R-state to T-state transition that involves substantial movements of domains. This rearrangement requires a trans - to cis - switch of a peptide backbone within the hinge region of Medtr ATP-PRT1. A C-terminal α-helix, absent in bacteria, reinforces the hinge that is constituted by two peptide strands. As a result, conformations of the R- and T-states are significantly different from the corresponding states of prokaryotic enzymes with known 3-D structures. Finally, adenosine 5'-monophosphate (AMP) bound at the active site is consistent with a competitive (and synergistic with histidine) nature of AMP inhibition.


  • Organizational Affiliation
    • Synchrotron Radiation Research Section of MCL, National Cancer Institute, S Cass Ave 9700, Argonne, IL, U.S.A. milosz.ruszkowski@nih.gov.

Macromolecule Content

  • Total Structure Weight: 232.11 kDa
  • Atom Count: 15,556
  • Modeled Residue Count: 2,012
  • Deposited Residue Count: 2,112
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP phosphoribosyltransferase catalytic subunit
A, B, C, D, E
A, B, C, D, E, F
352Medicago truncatulaMutation(s): 0
Gene Names: 11438625MTR_4g130680
EC: 2.4.2.17
UniProt
Find proteins for G7JFL4 (Medicago truncatula)
Explore G7JFL4
Go to UniProtKB:  G7JFL4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG7JFL4
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GOL

Query on GOL



Download:Ideal Coordinates CCD File
I [auth B],
K [auth C],
M [auth D],
O [auth E],
Q [auth F]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
G [auth A]
H [auth B]
J [auth C]
L [auth D]
N [auth E]
G [auth A],
H [auth B],
J [auth C],
L [auth D],
N [auth E],
P [auth F]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.92 Å
  • R-Value Free:  0.250 (Depositor), 0.244 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.198 (DCC)
  • R-Value Observed: 0.198 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.826α = 90
b = 195.621β = 95.85
c = 100.209γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XDSdata scaling
HKL-3000phasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-08-15
    Type: Initial release
  • Version 1.1: 2018-09-12
    Changes: Data collection, Database references
  • Version 1.2: 2024-03-13
    Changes: Data collection, Database references
