Crystal structure of the Deinococcus radiodurans Nramp/MntH divalent transition metal transporter G45R mutant in an inward occluded state

Experimental Data Snapshot

  • Resolution: 2.95 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.243
  • R-Value Observed: 0.244

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history


Structures in multiple conformations reveal distinct transition metal and proton pathways in an Nramp transporter.

Bozzi, A.T.Zimanyi, C.M.Nicoludis, J.M.Lee, B.K.Zhang, C.H.Gaudet, R.

(2019) Elife 8

  • DOI: https://doi.org/10.7554/eLife.41124
  • Primary Citation of Related Structures:
    6C3I, 6D91, 6D9W

  • PubMed Abstract:

    Nramp family transporters-expressed in organisms from bacteria to humans-enable uptake of essential divalent transition metals via an alternating-access mechanism that also involves proton transport. We present high-resolution structures of Deinococcus radiodurans (Dra)Nramp in multiple conformations to provide a thorough description of the Nramp transport cycle by identifying the key intramolecular rearrangements and changes to the metal coordination sphere. Strikingly, while metal transport requires cycling from outward- to inward-open states, efficient proton transport still occurs in outward-locked (but not inward-locked) DraNramp. We propose a model in which metal and proton enter the transporter via the same external pathway to the binding site, but follow separate routes to the cytoplasm, which could facilitate the co-transport of two cationic species. Our results illustrate the flexibility of the LeuT fold to support a broad range of substrate transport and conformational change mechanisms.

  • Organizational Affiliation

    Department of Molecular and Cellular Biology, Harvard University, Cambridge, United States.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Divalent metal cation transporter MntH
A, B
445Deinococcus radiodurans R1 = ATCC 13939 = DSM 20539Mutation(s): 1
Gene Names: mntHDR_1709
Membrane Entity: Yes
Find proteins for Q9RTP8 (Deinococcus radiodurans (strain ATCC 13939 / DSM 20539 / JCM 16871 / CCUG 27074 / LMG 4051 / NBRC 15346 / NCIMB 9279 / VKM B-1422 / R1))
Explore Q9RTP8
Go to UniProtKB:  Q9RTP8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9RTP8
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.727α = 90
b = 97.85β = 90
c = 118.257γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling
Cootmodel building
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States1R01GM120996-01A1

Revision History  (Full details and data files)

  • Version 1.0: 2019-02-13
    Type: Initial release
  • Version 1.1: 2019-02-20
    Changes: Data collection, Database references, Derived calculations
  • Version 1.2: 2020-01-01
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-04
    Changes: Data collection, Database references, Refinement description
