6BBU

Crystal Structure of JAK1 in complex with compound 25


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.183
  • R-Value Observed: 0.185

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Identification of N-{cis-3-[Methyl(7H-pyrrolo[2,3-d]pyrimidin-4-yl)amino]cyclobutyl}propane-1-sulfonamide (PF-04965842): A Selective JAK1 Clinical Candidate for the Treatment of Autoimmune Diseases.

Vazquez, M.L.Kaila, N.Strohbach, J.W.Trzupek, J.D.Brown, M.F.Flanagan, M.E.Mitton-Fry, M.J.Johnson, T.A.TenBrink, R.E.Arnold, E.P.Basak, A.Heasley, S.E.Kwon, S.Langille, J.Parikh, M.D.Griffin, S.H.Casavant, J.M.Duclos, B.A.Fenwick, A.E.Harris, T.M.Han, S.Caspers, N.Dowty, M.E.Yang, X.Banker, M.E.Hegen, M.Symanowicz, P.T.Li, L.Wang, L.Lin, T.H.Jussif, J.Clark, J.D.Telliez, J.B.Robinson, R.P.Unwalla, R.

(2018) J Med Chem 61: 1130-1152

  • DOI: 10.1021/acs.jmedchem.7b01598
  • Primary Citation of Related Structures:
    6BBU, 6BBV

  • PubMed Abstract:
  • Janus kinases (JAKs) are intracellular tyrosine kinases that mediate the signaling of numerous cytokines and growth factors involved in the regulation of immunity, inflammation, and hematopoiesis. As JAK1 pairs with JAK2, JAK3, and TYK2, a JAK1-selective inhibitor would be expected to inhibit many cytokines involved in inflammation and immune function while avoiding inhibition of the JAK2 homodimer regulating erythropoietin and thrombopoietin signaling ...

    Janus kinases (JAKs) are intracellular tyrosine kinases that mediate the signaling of numerous cytokines and growth factors involved in the regulation of immunity, inflammation, and hematopoiesis. As JAK1 pairs with JAK2, JAK3, and TYK2, a JAK1-selective inhibitor would be expected to inhibit many cytokines involved in inflammation and immune function while avoiding inhibition of the JAK2 homodimer regulating erythropoietin and thrombopoietin signaling. Our efforts began with tofacitinib, an oral JAK inhibitor approved for the treatment of rheumatoid arthritis. Through modification of the 3-aminopiperidine linker in tofacitinib, we discovered highly selective JAK1 inhibitors with nanomolar potency in a human whole blood assay. Improvements in JAK1 potency and selectivity were achieved via structural modifications suggested by X-ray crystallographic analysis. After demonstrating efficacy in a rat adjuvant-induced arthritis (rAIA) model, PF-04965842 (25) was nominated as a clinical candidate for the treatment of JAK1-mediated autoimmune diseases.


    Organizational Affiliation

    Medicine Design, Pfizer Inc , 1 Portland Street, Cambridge, Massachusetts 02139, United States.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tyrosine-protein kinase JAK1A316Homo sapiensMutation(s): 0
Gene Names: JAK1JAK1AJAK1B
EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for P23458 (Homo sapiens)
Explore P23458
Go to UniProtKB:  P23458
PHAROS:  P23458
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
D7D (Subject of Investigation/LOI)
Query on D7D

Download Ideal Coordinates CCD File
B [auth A]N-{cis-3-[methyl(7H-pyrrolo[2,3-d]pyrimidin-4-yl)amino]cyclobutyl}propane-1-sulfonamide
C14 H21 N5 O2 S
IUEWXNHSKRWHDY-PHIMTYICSA-N
 Ligand Interaction
Modified Residues  1 Unique
IDChainsTypeFormula2D DiagramParent
PTR
Query on PTR
AL-PEPTIDE LINKINGC9 H12 N O6 PTYR
Binding Affinity Annotations
IDSourceBinding Affinity
D7D BindingDB:  6BBU IC50: min: 5.1, max: 2511 (nM) from 9 assay(s)
Binding MOAD:  6BBU IC50: 29 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.08 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.183
  • R-Value Observed: 0.185
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.53α = 90
b = 88.1β = 90
c = 146.05γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
XSCALEdata scaling
BUSTERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

  • Deposited Date: 2017-10-19
  • Released Date: 2018-01-17
  • Deposition Author(s): Han, S.

Revision History  (Full details and data files)

  • Version 1.0: 2018-01-17
    Type: Initial release
  • Version 1.1: 2018-02-21
    Changes: Database references
