6AQK | pdb_00006aqk

Crystal structure of the C-terminal toxin domain of RHS2 from Yersinia entomophaga

PDB DOI: https://doi.org/10.2210/pdb6AQK/pdb

Classification: TOXIN
Organism(s): Yersinia entomophaga
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-08-20 Released: 2018-08-22
Deposition Author(s): Busby, J.N., Hurst, M.R.H., Lott, J.S.
Funding Organization(s): Marsden Fund

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.226 (Depositor), 0.226 (DCC)
R-Value Work:
0.181 (Depositor), 0.181 (DCC)
R-Value Observed:
0.183 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6AQK

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of the C-terminal toxin domain of RHS2 from Yersinia entomophaga

Busby, J.N., Hurst, M.R.H., Lott, J.S.

To be published.

Macromolecule Content

Total Structure Weight: 27.63 kDa
Atom Count: 1,804
Modeled Residue Count: 216
Deposited Residue Count: 230
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Toxin protein	A	230	Yersinia entomophaga	Mutation(s): 0 Gene Names: RHS2
UniProt
Find proteins for A0A2D0TC51 (Yersinia entomophaga) Explore A0A2D0TC51 Go to UniProtKB: A0A2D0TC51
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A2D0TC51
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PT Query on PT Download:Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A]	B [auth A] C [auth A] D [auth A] E [auth A] F [auth A] B [auth A], C [auth A], D [auth A], E [auth A], F [auth A], G [auth A]	PLATINUM (II) ION Pt HRGDZIGMBDGFTC-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
BR Query on BR Download:Ideal Coordinates CCD File SDF format, chain Q [auth A] MOL2 format, chain Q [auth A] mmCIF format, chain Q [auth A]	Q [auth A]	BROMIDE ION Br CPELXLSAUQHCOX-UHFFFAOYSA-M		Interactions Focus chain Q [auth A] Interactions & Density Focus chain Q [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	H [auth A] I [auth A] J [auth A] K [auth A] L [auth A] H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.226 (Depositor), 0.226 (DCC)
R-Value Work: 0.181 (Depositor), 0.181 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.51	α = 90
b = 54.52	β = 90
c = 100.82	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Blu-Ice	data collection
XDS	data extraction
XSCALE	data scaling
Aimless	data reduction
SHELXDE	phasing
DM	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2018-08-22

Deposition Author(s):

Funding Organization	Location	Grant Number
Marsden Fund	New Zealand	14-UOA-146

Revision History (Full details and data files)

Version 1.0: 2018-08-22
Type: Initial release
Version 1.1: 2024-03-13
Changes: Data collection, Database references
